MAIN FEATURES
01Adopt YTO diesel engine, good reliability, large reserves of torque, low fuel consumption, high economic efficiency.
02Double-function clutch, operate independently, high transmission capacity, effective and reliable, comfortable operation.
03Gearbox using 4 × (4+2) engaging sleeve, shuttle-type gearshift , there are 16 forward gears, 8reverse gears, reasonable match between the gears, and have high efficiency.
04Independent power take off device, smooth transmission, large capacity.
05Full hydraulic front wheels steering, independent oil circuit for steering system, manipulating flexible, reliable, and save energy.
06Adopt hydrostatic disc-type brakes, a large braking torque, the braking effect is good.
07Adopt high pressure type lifting device, reliable, easy maintenance, multi-hydraulic output can be optioned.
08Final transmission adopts planetary gear mechanism, compact structure, large reduction ratio.
09New streamlined appearance, generous, modern, fashion.
MAIN TECHNICAL PARAMETER

Tractor Model		LT704
Drive Type		4×4
Overall Dimension L×W×H(mm)		4396×2038×2810
Wheel base(mm)		2195
Front wheel tread(mm)		1610
Rear wheel tread(mm)		1620-2020
Min. ground clearance(mm)		379
Min. steering radius	Unilateral brake(m)	4.2±0.3
	Not unilateral brake(m)	4.9±0.3
Min. operating weight (KG)		4090
Gearbox gears number		16F+8R
Speed	Forward(Kw/h)	1.58-33.69
	Reverse(Kw/h)	2.41-34.67
Engine	Model	LR4M5-23
	Rated power (Kw)	66.2
	Rated speed (r/min)	2300
Tires spec.	Front tires	11.2-24
	Rear tires	16.9-34
Steering Type		Full hydraulic front wheels steering
Max. lifting force( KN )		15.9
PTO	Type	Rear-mounted, Independent type
	Speed (r/min)	760/1000 or 540/1000 or 540/760 or 760/850
	Power(Kw)	56.3
Control type of ploughing depth		Height control & flotation control
Max. traction force (KN)		15.9
Front / rear Ballast (KG)		270/470
