Plastic PP Woven Bags PE Film Squeezing Pelletizing Dewatering Squeezer Machine Drying Machine
| US$5,000.00-9,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
XT300-400
Material Processed
Film
Plastic Type
PE
Screw
Single-Screw
Automation
Automation
Computerized
Non-Computerized
Certification
QS, GMP, ISO9001:2008, CE
Type
Film-Squeezing Machine
Power Consuption
Low
After Sales Service
Video Technical Support, Free Spare Parts
Capacity
300/500/1000kg/H
Voltage
380V, 50Hz or Customized
Motor
Siemens Brand
Contactor
Schneider
Power(W)
100-500kw
Key Selling Points
Multifunctional
Inverter
ABB Brand
Name
Plastic Squeezing Machine
Transport Package
Film Packing or Woodcase Package
Specification
6.8cbm
Trademark
XINTING
Origin
Zhangjiagang China
HS Code
8477201000
Production Capacity
300-800kg/Hr, 300-800kg/H
Packaging & Delivery
Package Size
160.00cm * 100.00cm * 200.00cm
Package Gross Weight
5000.000kg
Product Description
plastic PP Woven Bags PE Film dewatering Squeezing pelletizing squeezer Machine Drying MachineMachine description
This is new type film-squeezing machine which is designed by our company. It use squeezing & dehydration principle, after raw material (LDPE agriculture film, LLDPE strength film, and PP woven/big bags, etc) crushing and washing, this squeezer machine can quickly and effectively remove the water. It is easy to increase the subsequent granulating line production capacity.
Output capacity : ≈400-500kg/h (according to material status)
Motor power :90KW (AC, Siemens Beide)
Inverter :ABB , With high and low voltage protection, current overload protection, short circuit detection, etc.
Screw, barrel Material: high quality alloy steel
Screw diameter: Ø300-400 mm
Screw rotation speed: 60 rpm
Reduction gearbox High torque, compact structure
Material of main box: QT400
Material of gear: 20GrMnTi
Accuracy of gear: 6 grade, HRC56-62 of face, core material hardness: HB265
Lubrication system: circulating oil enforced by oil pump, infiltration and splash in oil basin
With plate heat exchanger to cool the gear oil by transmit heat to the cooling water inside the exchanger.
Cutting motor power :4KW
Number of blade: 4pcs
Heating power :8.5KW
Air convey motor power: 5.5KW
Final product:PE flakes, moisture content 3-5%, Can be use for pelletizing directly, no need agglomerator
Main technical parameters:
| Model | Motor | Screw diameter | Air cooling motor | Silo volume | Capacity(Kg/hour) |
| SQ300 | 55kw | 250mm | 3kw | 300L | 300kg/h |
| SQ500 | 90kw | 320mm | 3kw | 300L | 500-800kg/h |
