High-Efficiency Plasterboard and Gypsum Board Manufacturing Line

Product Description

Product Parameters

Gypsum board pro Product Description

duction line

Our company has many years of experience in producing gypsum board and gypsum powder production line, identified by the Commerce Department as Designated Equipment Manufacturer. According to our more than ten years experience and surveys from the customers, we always provide advanced technology content, high reliability ,lower operation and qualified gypsum board technology scheme.

Characteristics of the equipment
Easy to form a complete equipment.The key electronic components use the high quality products from the internationally known company.
The scale of production and the area of the plant are moderate and match the automation and the mechanization of the production line, which is easy to manage.
The production line adopts Germany's advanced technology and our researching personnel research on the main parts such as dosing, forming and drying to design high efficiency, stability and energy saving production line.

Product Details
Dosing system
1)The dosing system has a high accuracy .
2)Starch mixing tank use stainless steel, with long service life and low corrosive.The foaming agent reserve tank is made of
stainless steel.
3)Foaming system adopts domestic advanced technology-Dynamic and static foaming system, ensuring the finished board is lightweight, good bending strength and it can help to saving much cost.

Paper supply system
Adopting pneumatic tension bridle shaft to clamp paper rolls, improving production speed, reducing the labor intensity when manual clamping.
Reduce the waste of paper and the manual jobs and improve the joint neat standard.
Automatic cutting machine
With the adoption of developed core servo cutting technology of our company, adjusting the required plate dimension by digital controller.
Maximally reducing cost by controlling the minimum edge horn size.
The whole cutting system is controlled by servo machine, applying to diversity of products.

Forming&Solidification System


Adaption of our company newly developed core slurry receiving machine and discharging material technology avoids the
inconsistency of manual operation, and ensures the quality of gypsum board, and reduces the manual jobs.
A complete set of molding system controlled by frequency conversion, adapting to the diversity of the product.


Drying system






Full automatic control, without manual operation.Characteristics :(A) less manual work (B) improving drying efficiency of the
drying machine (C) save energy consumption (D) improving the immanent quality of gypsum board and the first rate of all products.
Adopting steam recycling environmental protection and energy saving device developed independently by our company to save water consumption greatly.
Discharging board and finished board system
Parts and components manufactured elaborately is to ensure the reliability of the whole system.
Digital automatically adjust the saw cutting width.
Adopting servo motor control, ensuring the precision of the position plate movement, to adapt to the diversity of the roduct.

Gypsum board

Gypsum board specification
length(mm)	2400,2440,2500,2700,3000
width(mm)	1200,1220
discrepancy of the length and width(mm)	Length 0-6 Width 0-5
thickness(mm)	8,9,9.5,12,12.5,12.7,15,18
discrepancy of the thickness(mm)	0±0.5 0±0.6
discrepancy of the diagonal(mm)	≤5
crippling load of the board(N)	9.5: portrait>=360 landscape orientation >=140 12: portrait ≥500 landscape orientation ≥180
rate of water content	<2%

Project Case

12 Years experience in oversea market projects service No projects of failure.
1) Experience in gypsum technology research since 1998
2) Experience of 100+ projects manufacture &install abroad and domestic
3)Products available in 20+countries

Why Choose Us

What we provide is not ONLY the machine BUT the whole system.
Yurui (Shandong) Machinery Co., Ltd, is an enterprise integrating gypsum projects R&D, design, Manufacturing, exportation, installation, and commissioning.
We have been deeply engaged in the field since 1998, setting up 100+gypsum projects domestic and abroad. Our engineers group who only serve for YURUI left a full footprint over Africa, Asia, and south America, total of 20+countries. We hold different projects in each area, offering case visiting on-site. Besides we developed online visiting which breaks the limit of the virus.
We are not a machinery provider, but an overall solution provider.
We focus on the demands of users, never stop updating, improving, and surpassing.
We pursue extreme cost performance, not only price.
Our factory
1) Experienced installation group gets projects into production quickly.
How do we ensure the fact installation? Besides the "people", we provide the installation documents which accompany our machinery.In addition, we extra provide all the relevant documents to enhance your production.
2) the Whole group provide a powerful One-stop sourcing service
We assist our customers in the procurement of all relevant spare parts, saving them time to the greatest extent and preventing downtime due to spare parts. At the same time, we ensure the maximum adaptability of the parts purchased later to the original equipment.Packing
Service

1) Pre-sales: Full cooperation with pre-preparation work
2) In-sales: On-time reporting of production progress
3) After-Sales: Lifetime & 24h technical support

FAQ

Q: How long is the warranty of your equipment? A: 1 year

Q: Do you supply spare parts?
A: Excellent easy broken parts support for buyers. Easy broken parts guarantee for one year.

Q: Will you provide training?
A: The training is free of charge , and our engineer will be on duty to train your worker.

Q: How will you provide installation&commissioning?
A: Will provide 2~8 persons(adjustable according to the degree of automatic )for installation. Engineers team will go with your project.

Q:How long time for the installation and commissioning?
A: depend on configuration normally only need 15-25 days. Including workers training.
