Top Manufacturer for Large Double Side Cold and Hot Laminating Machine Support OEM

Product Description

Top Manufacturer for Large Double Side Cold and Hot Laminating Machine Support OEM
Product Description
Our Hanspire double-sided laminating machine is developed relying on its own technical advantages and market demand.It can work with single side,double sides,cold film and foils as well.Multifunctional design, simple operation, stable mechanical performance and careful after-sales service, committed to bring you satisfactory use experience.
The Laminating machine with PET or Bopp film as the material as usual, can be widely used in packing box, food box, books, drawings, advertisements, certificates and so on, the printing after the film waterproof, durable, clear pattern.
Product Specification

Model	FM-360	FM-480	FM-650	FM-1100
Laminating Width	340mm	460mm	635mm	1050mm
Max. Laminating Thickness	5mm	5mm	5mm	5mm
Max. Laminating Speed	3000mm/min	3000mm/min	3000mm/min	3000mm/min
Max. Laminating Temperature	Hot Lamination:60ºC-160ºC Cold Lamination:20ºC-60ºC
Electricity Supply	AC110,220/50,60Hz,650W	110,220v/50,60Hz 1200W	110,250v/50,60Hz 1600W	110,220v/50,60Hz 3300W,16A
Motor Power	30W	30W	30W	50W
Dia.of Heating Rubber Roller	45mm	45mm	55mm	75mm
Dia.of Discharging Roller	30mm	30mm	45mm	55mm
Mold Core Size	1 inch, 3 inches	1 inch, 3 inches	1 inch, 3 inches	3 inches
Machine Size (L x W x H)	640×440×285mm	720×440×310mm	910×520×310mm	1350×600×1250mm
Weight	32kg	48kg	80kg	160kg

Product Advantage
1.Double side Laminating,meet your different require2.LCD display,Easy operation for different functions3.Yellow safety cover , protect your hands4. Quick change for film core ,One inch or Three inch5. Install large diameter film roll, reduce times for change film6. Machine stand is optional(FM-360), others include stand.7. Export standard package
8. Hot stamping function is optional
9. Both workable for Hot and Cold Laminating
