radial arm drilling machine ZQ3063x20 manual type radial drilling machine

Product Description

Product Description
Radial drilling machine ZQ3063x20 main features:
1. Transmission: Mechanical transmission;
2. Max. drilling diameter: 63mm;
3. Spindle taper: Morse 5;
4. Spindle travel: 400mm.

Main technical parameters	ZQ3063X20
drilled diameter( mm)	63
Distance from spindle end face to workbench( mm)	400-1150
Distance from spindle to column busbar (mm)	400 -1700
travel of spindle( mm)	310
Spindle cone hole (Mohs)	Mt5
range of spindle speeds( r.p.m)	34-1280
number of spindle speeds	12(steps)
Spindle feed amount range	0.06-0.53
Spindle feed series	6(steps)
Rocker arm swing angle (°)	360
Power of main motor (KW)	5.5
Lift motor power (KW)	1.5
Machine tool weight ( KG)	3000
outline dimension( mm)	2600x1050x2450

Guarantee Terms:
Complete service by free of charge within 13 months after B/L date Technical service will be given forever at any time. Any questions during operation, can contact us freely by email, or contact on line by Skype, WhatsApp, etc. Also can talk face to face during fairs. You will get response within 20 hours. Company Profile
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What's the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
