ZSK4830 CNC rotary multi-station drilling and tapping machine

Product Description

Product Description
CNC rotary multi-station drilling and tapping machine ZSK4830

Model	ZSK4830
Max. Drilling capacity(mm)	30/25
Max. Tapping capacity(mm)	M24/M20
Max.spindle travel(mm)	130
Morse taper of spindle nose	MT.3
Spindle speeds(r/min)	140-220-320-370-460-550-1100-1170-1780
Spindle feed drive mode	CNC Servo
Spindle feeds(mm/min)	0.1-2000
Max. spindle speed(mm/min)	7500
Size of worktable(mm)	800
Machining axis diameter(mm)	550-620
Table travel time(s)	2
Distance from spindle axis to column surface(mm)	235
Distance from spindle to worktable(mm)	350-700
Main motor power(kw)	Drilling: 1.1(6 steps) Tapping: 1.1(6 steps)
Machine weight(kg)	1300
Machine size(cm)	168*178*210

Company Profile
Customers' Feedback
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2:Can we visit your factory before order?
A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides,we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3:Do you have a stock?
A3:Sorry, most of our machines don't have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4:What's the MOQ?
A4:One set only.
Q5:How about your quality?
A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6:Do you have professional engineers?
A6:Yes.we have professional engineers and designers. We can provide OEM services.
Q7:Can you provide customized machines?
A7:Yes, we can design and manufacture according to your specific requirements.
