High Efficiency HDPE Pipe PE100 Large Diameter Polyethylene Pipe for Gas Supply

Product Description

Product Description
This series of products are new-type medium, high or low-pressure composite pipes reinforced by high-strength plastic-covered steel wire and covered with composite thermal plastic at internal and external surface. Owning to the reinforcement is covered in continuous thermal plastic, this kind of composite pipe not only overcomes shortcomings of steel pipes and plastic pipes, but also has common advantages of steel pipes and plastic steels. After the galvanized pipe is prohibited, it is a revolutionary technological achievement for architectural and municipal water supply pipe and also solves the urgent needs for large-diameter rigid pipes in petroleum, chemical engineering, pharmacy, food, mine and gas field, etc. The piping system of steel wire mesh plastic reinforced composite pipes is equipped with electric melting pipe fittings. During connection, the heating elements in fittings will melt outer plastic on pipe and inner plastic on fittings and then connect them together reliably.
Product Parameters

Normal Diameter (DN/OD) (mm)	Wall thickness (mm)
	PN8	PN10	PN16	PN20
	0.8MPa	1.0MPa	1.6MPa	2.0MPa
50	-	-	4.5	5.0
63	-	-	4.5	5.0
75	-	-	5.0	5.0
90	-	-	5.5	5.5
110	-	5.5	7.0	7.0
140	-	5.5	8.0	8.5
160	-	6.0	9.0	9.5
200	-	6.0	9.5	10.5
225	-	8.0	10.0	10.5
250	8.0	10.5	12.0	12.0
315	9.5	11.5	13.0	13.0
355	10.0	12.0	14.0	-
400	10.5	12.5	15.0	-
450	11.5	13.5	15.0	-
500	12.5	15.5	18.0	-
560	17.0	20.0	-	-
630	20.0	23.0	-	-

HOW TO CONNECT HDPE PIPE :
connect steel wire mesh skeleton reinforced pe100 HDPE composite pipe SRTP pipe has two mothrod ,one use EF fittings , and other use flange connect Our Advantages
Durability: Its hygienic indexes shall meet provisions in GB/T17219 "Standard for Hygienic Safety Evaluation of Equipment and Protective Materials in Drinking Water". The product shall meet provisions in standard CJ/T189-2007. Flexibility: The color is generally black and also can be decided according to mutual agreement of the supply and requisitioning parties. The internal and external surface of the pipe shall be smooth, may be have small pits and bumps formed during natural shrinking and be free of any bubble, crack, decomposition discoloration and obvious scratch. And, two ends of the pipe shall be cut flatly.Corrosion Resistance: he technology to connect pipes by electric melting is mature, electric-melting joints are highly resistant to axial tension and multiple fittings of various specifications and varieties are available. Lightweight: pipes are significantly lighter than their metallic counterparts, making transportation, handling, and installation more convenient and cost-effective. The reduced weight does not compromise the structural integrity of the pipes, ensuring reliable performance.Leak-Free Joints: The technology to connect pipes by electric melting is mature, electric-melting joints are highly resistant to axial tension and multiple fittings of various specifications and varieties are available. Versatility: suitable for a wide range of applications, including potable water distribution, wastewater management, industrial processes, and more. It is the best substitute of galvanized pipe because it is low in cost, hygienic and non-toxic. Company Profile
Our History
Shandong KANGYU Pipe Industry Co., Ltd. is a professional manufacturer and supplier of high-quality HDPE pipes, PPR pipes, PVC pipes, and pipe fittings. The company is located near the Qingdao Port, an important transportation hub of China, which facilitates the delivery of products to the market and enables efficient and convenient logistics.
Founded in 2009, KANGYU has a total of 700 employees and 30 production lines. The company has an annual output value of 100 million US dollars and has attained ISO9001 certification and various quality systems certification. KANGYU's products have been highly recognized by customers both domestically and internationally.
Main Products
HDPE Pipes and Pipe Fittings:
KANGYU provides HDPE pipes for water supply and gas transmission. The pipes have high flexibility, high impact resistance, corrosion resistance, and long service life. The pipe fitting products include butt fusion fittings, electrofusion fittings, saddle clamps, and mechanical fittings, which are widely applied in municipal engineering, building water supply, gas pipeline, and coal mine drainage systems.
PPR Pipes and Pipe Fittings:
KANGYU offers a full range of PPR pipes for hot and cold water transportation. The pipes have excellent heat resistance, pressure resistance, and chemical resistance, making them suitable for a wide range of applications, such as residential and commercial buildings, hotels, hospitals, and schools. The PPR pipe fittings include socket fusion fittings, brass fittings, and welding instruments, which ensure a reliable and easy installation process.
PVC Pipes and Pipe Fittings:
KANGYU manufactures PVC pipes for drainage and electric conduits. The PVC pipes have superior corrosion resistance, electrical insulation, and low thermal conductivity. The pipe fittings are made of high-quality PVC materials, which provide excellent chemical resistance, impact resistance, and dimensional stability.
Positive Outlook
Shandong KANGYU Pipe Industry Co., Ltd. adheres to the business philosophy of "quality first, customer first" and strives to provide customers with the best products and services. The company has a sound management system, advanced production technology, and a strong R&D team, which ensures the continuous improvement and innovation of product quality and performance.
In the future, Shandong KANGYU Pipe Industry Co., Ltd. will continue to focus on the development of high-tech pipe products, actively explore new markets, and cooperate with partners to achieve mutual benefits and win-win results. We believe that through joint efforts, the company will have a brighter future and create value for both customers and society.
Our Factory
In order to build a modern factory, we invest in a series of professional mechanical equipment. The annual output amounts to 30000 tons, which can fill up 3000 containers.
The excellent machinery and consummate management system can reduce cost, shorten delivery time and ensure the quality of every product.
Certifications
We have passed CE, SGS, ISO, CNAS, IAF certification and our products compound international standards
Packaging & Shipping
FAQ
Q1: May I get one sample before placing order?
A: Yes, Sample are available. For normal products, samples are for free and you just need to bear the freight; For those high value products, you just need to freight and certain product cost. When we both cooperate for some times or when you are our VIP customer, free sample will be offered when you need.
Q2: Which payment is available for your company?
A: T/T, L/C or Ali trade insurance. You can choose the one which is convenient for you.
Q3: How and when can I get my goods after payment?
A: For small quantity products, they will be delivered to you by international courier(DHL, FedEx, TNT etc.) or by air. Usually it will cost 3-5days that you can get the goods after delivery. For large quantity products,shipping by see is worthwhile.It will cost days to weeks to come to your destination port, which depends on where the port is.
Q4: Is there any possible to use my appointed label or package?
A: Yes. If needed, we'd like to use label or package according to your requirement.
Q5: How can you guarantee the goods you offer is qualified?
A: We always believe honesty and responsibility are basis of one company, so whatever products we provide for you all are qualified. We will have goods tested and provide COA before delivery for sure.
Q6: Is the price on this page correct?
A: The listed price is only for reference, for latest price, pls contact us directly.
Q7: How can I get some samples?A: We are honored to offer you free samples, just need to pay the freight cost.
OUR TEAM
