Large Crushing Ratio Hydraulic Opening Layout Crushing Equipment Good Particle Shape Impact Crusher for Metallurgical Industry

Product Description

Large Crushing Ratio Hydraulic Opening Layout Crushing Equipment Good Particle Shape Impact Crusher For Metallurgical Industry Product Information
This series of products is a three-chamber impact crusher developed by our company after optimizing the design. It has the characteristics of reasonable structure, large crushing ratio, high output, low energy consumption, and convenient maintenance. It is particularly suitable for the medium and fine crushing of various materials with a compressive strength not exceeding 250Mpa. It is an ideal equipment for crushing materials used in high-grade highways, railways, hydropower, chemicals, building refractory materials, ceramics, glass and other industries. This series of products is a three-chamber impact crusher developed by our company after optimizing the design. It has the characteristics of reasonable structure, large crushing ratio, high output, low energy consumption, and convenient maintenance. It is particularly suitable for the medium and fine crushing of various materials with a compressive strength not exceeding 250Mpa. It is an ideal equipment for crushing materials used in high-grade highways, railways, hydropower, chemicals, building refractory materials, ceramics, glass and other industries.
Technical Details

Model	Motor Power(KW)	Processing capacity (t/h)	Maximum feed port size (mm)	Discharging Granularity(mm)	Dimensions(mm)
PFY-1214	160	100-200	350	0-70	3090×2300×2633
PFY-1315	200	150-250	400	0-80	3165×2670×2870
PFY-1515	280	250-400	500	0-100	3524×2694×3040
PFY-1518	400	300-600	500	0-100	3524×3330×3040
PFY-1620	500	350-700	500	0-120	3571×3828×3394

Advantages
1. The special oversized cavity design greatly improves the crushing rate and production capacity;
2. Compared with the same type of equipment in the same industry, our company's crushing capacity can be increased by 10-25%;
3. The three-cavity structure is adopted, and the shape of the finished material is better;
4. The non-circular rotor structure design gives full play to the throwing function of the plate hammer, greatly improves the crushing efficiency, reduces the wear of the plate hammer, and under the same conditions, the service life of the plate hammer is extended by about 20%.
5. The hydraulic cover opening structure is adopted, and the maintenance and replacement of accessories are simple and convenient;
6. Simple operation and convenient maintenance.
Process
Applicable Materials
Applicable to the production of all machine-made sand in the sand and gravel aggregate industry, including common limestone, river pebble, basalt, granite, iron ore, construction waste, etc.Different models match different materials.
Packing
Company Profile
Chongqing Sanming Heavy Industry Co., Ltd. was established in 1994 as a comprehensive equipment manufacturing company that integrates scientific research, production, sales and service. Adhering to the business philosophy of "honesty, pragmatism and innovation", and focusing on the product orientation of "intelligence, high efficiency, energy conservation and environmental protection," with 30 years of innovative development, Sanming's products now include stone crusher and screening equipment, casting spare parts, intelligent control systems, and EPC general contracting projects, covering numerous industries such as mining, building materials, highways, railways, bridges, coal, metallurgy and chemical industry. It has become a national high-tech company.
Certification
Main Product
Workshop
Finished product workshop
Production workshop
Foundry workshop
Test platform
Create a complete equipment test site for customers to more intuitively display product effects.Including jaw crusher, cone crusher, impact crusher and other machines
Project Case
After Sales Service
We win market respect with quality and win customer trust with professional services.
We carefully inspect and accept each production line, so that customers can put it into production with confidence.
We carry out quality tours all year round, and always adhere to the win-win development concept of "same heart, same virtue, same trade, same sharing".

Exhibition
FAQ
1.Can I have a sample order?
A: Yes.
2.What about the leading time ?
A: 15 working days.

3.Do you have any MOQ limit ?
A: MOQ is 1 set.

4.Can you provide OEM and ODM services?
A: Yes.

5.Will you provide pre-sale services ?
A: Yes. SAMYHI consists of experienced specialists, we will offer a suitable solution according client's requirement in time.
6.Is our after-sales service excellent ?
A: Yes. SAMYHI's skilled technicians are available to assist with onsite installation,commissioning & training on request.
7.Will we provide technical support ?
A: SAMYHI provides enough hardware resource especially for large-scale production lines, clients can carry out installation, commissioning and acceptance before delivery.

Large Crushing Ratio Hydraulic Opening Layout Crushing Equipment Good Particle Shape Impact Crusher For Metallurgical Industry
