Tower Manufacture Machine FINCM Tower Structure Fabrication Angle CNC Marking Shearing and Punching Machine

Product Description

Product Description
APM0908 FINCM Tower Structure Fabrication Angle CNC Marking Shearing and Punching Machine 40mm*40mm*3mm-90mm*90mm*8mm
It is mainly used for customers to manufacture angle steel components, complete typing, punching, fixed length cutting on angle steel. Simple operation, high production efficiency.

Technical specification of APM0908

Model	APM0908
Angle Size (mm)	40x40x3~90x90x8(Q345)
Max. workpiece length (m)	12
Max. punching capacity(DxT mm)	Φ25.5mm x8mm
Nominal punching force (kN)	350
Nominal marking force (kN)	1030
Nominal cutting force (kN)	1000
No. of character group (piece)	4
No. of character in each character group (piece)	18
Character size (mm)	14x10x19
Range of stadia (mm)	20~170 (stepless)
No. of punch on each side (piece)	3
Max. feeding speed (m/min)	40
No. of CNC axes (piece)	3
Overall size (m)	25x7x2.2
Total power (kW)	31.4
Machine weight (kg)	Approx. 15000

Angle feeding Speed: 40m/min, the effiency is about 1000 holes/hour
The finished angle conveyor is rotated to one side by pneumatic power. The max. Length of finished angle is 8 m.
There are four transverse conveyors which can infeed automatically.
Type of programming: Keyboard input, USB interface input, floppy disc input.
Working environment:
Working temperature: 0~ 40 degree
Power: Three phase four wire system
AC Voltage: 380V
Fluctuation of voltage: ± 10%
Frequency: 50 Hz
Main outsourcing components list of APM0908:

No	Name	Brand	Manufacture
1	AC servo motor	Delta	Taiwan China
2	PLC	Delta	Taiwan China
3	Electromagnetic valve	Atos/Yuken	Italy/Tawan
4	Relief valve	Atos/Yuken	Italy/Tawan
5	Double vane pump	Albert	USA
6	Air valve	SMC/Airtac	Japan/Taiwan China
7	cylinder	SMC	Japan
