High Quality SMPS AC to DC Single Output Switching Power Supply 200W 48V 4.17A Hlg-200-48 Industrial Power Supplies with Pfc
Basic Info.
Model NO.
HLG-200-48
Driving Method
LED Constant Current
Circuit Structure
Conventional Step-down Transformer
Certification
CE, RoHS, ISO9001
Power Supply Mode
Constant Current Source
Modulation System
PWM
In-Out
Step-down Type
Power Supply Voltage
95~264
Brand
Weho
Dimension
205*69*43mm
Weight
1.1kg
Packing
20PCS
Impulse Current
Cold Start Current 45A/230VAC
Efficiency
92%
Wave and Noise
180MVP-P
Transport Package
Carton or Plywood Case
Specification
170*69*43mm
Trademark
WEHO
Origin
Zhejiang
HS Code
8504401400
Production Capacity
50000/Year
Packaging & Delivery
Package Size
20.50cm * 6.90cm * 4.30cm
Package Gross Weight
1.100kg
Product Description
Product Description High Quality Smps Ac to Dc Single Output Switching Power Supply 200W 48V 4.17A HLG-200-48 Industrial Power Supplies With PFCFeatures:
1. 95-264V AC Input Full Range Voltage
2. Protections: Short circuit / Overload / Over voltage / Over temperature
3. 100% full load burn-in test
4. Low cost, high reliability
5. 24 months warranty
Detailed Photos
Product Parameters
| Mode | HLG-200-12 | HLG-200 | HLG-200-36 | HLG-200-48 |
| DCoutput voltage,rated current | 12V 16.5A | 24V 8.3A | 36V 5.6A | 48V 4.2A |
| Wave andnoise | 180mVp-P | 200mVp-p | 220mVp-P | 220mVp-p |
| Lineregulation | 0.5% | ±0.5% | ±0.5% | ±0.5% |
| Load regulation | ±2% | 0.5% | ±0.5% | 0.5% |
| Efficiency | 90% | 91.5% | 93% | 93.5% |
| Voltage accuracy | ±3% | ±2% | ±2% | ±2% |
| Input voltage range | 95~264VAC/135~373VDC 47~63Hz | |||
| Impact current | Cold start current 45A/230VAC | |||
| Overcurrent protection | 95%~108%of therated output current starts overcurrent limit,recover automatically after abnormal conditions areremoved | |||
| Short circuit protection | Hiccup mode:recover automatically output after abnormal conditionsareremoved | |||
| Setup,rise,hold uptime | 200ms,30ms,20ms/230VAC (at fullload) | |||
| Pressure resistance | I/P-O/P:1.5kV I/P-FG:1.5kV O/P-FG:0.5kV | |||
| Isolation resistance | I/P-O/P I/P-FG O/P-FG:100MOhms/500VDC/25ºC /70%RH | |||
| Working temperature | 20C~+60C | |||
| Dimension | 205×69×43mm | |||
| Weight | 1.1kg | |||
| Packing | 16PCS | |||
Packaging & Shipping
Company Profile
FAQ Q1:Are you a factory or trading company?
A1:We are factory.
Q2:Why choose us
A2:We have been engaged in the switching power supply industry for 17 years,We have enough experience to meet your needs.
Q3:How can I get the samples?
A3:You can pay for the sample this time, and we will refund the sample fee for the next batch order.
Q4:How to order?
A7:Please contact us online to send you a proforma invoice or send us your purchase order by email.
Q5:How many years warranty of your switching power supply?
A8: Three years.
