Compact Electric Hoist and Trolley Combo for Easy Transport

Product Description

Product Details:
Place of Origin: Jiangsu , China
Brand Name: SEAGULL
Certification: CE
Model Number: Industrial Lifting Equipment Super Alloy Steel Chain Electrical Hoist
Payment & Shipping Terms:
Minimum Order Quantity: 30 pieces
Price: Negotiable
Packaging Details: wooden box.
Delivery Time: 30 days after confirming the contract
Supply Ability: 10000 pieces per year

PRODUCT DESCRIPTION
Capacity:0.5t,1t,2t,3t,5t,7,5t,10t,15t,25t,30t,35t.
Motor: Work class F insulation.
Duty rating:45%.Aluminum alloy motor with light weight and good heat dissipation to allow up 30minof continuous duty work at least.
Gear: All the gearing process by CNC Digital lathe with heat treating
Shelly:Made of light aluminum alloy shell.Light&hard. The cooling fin is especially designed to ensure quick heat dissipationwith the rate up to 45% and continuous service. The integral enclosed structure is applicable to places like chemical plate andelectroplate factroy
Side magnetic braking device:The magnetic orce generator is the lastest design which is featured for generating magnetic force. It allowsinstant brake cut off electric power asap.Keep the braking safety while loading is guaranteed
Limit switch :The limit switch automatically stop the hoist overlifting or overlowering
Chain: FEC JAPAN made G-80 super alloy steel chain.Heat treated to used in harsh environments .
Hook: Hot fored with perfect strength and tough with saftey latch on the top&bottom hook. Bottom hook swivels through 360°
Support frame:The loading support frame consists of two steel plates which is extremely sturdy
Transformer:24/36V transformer device forbid unexpected accidents such as electric leakage.
Electromagnetic contactor: It can use safely under high frequency
Packing It wonn't work when error wiring connecting by the end user to keep safe
Control button: IP 54 protection on electric hoist for dust and water proof protection.36V control
TECHINAL PARAMETERS
