3/8 1sn Braid Hydraulic Hose Pipe SAE 100r1 En853 Pressure Industrial Hose Assembly

Product Description

Industrial SAE 100r1at Braid Hydraulic Hose SAE100R1AT / DIN 1SN Descriptions:
Tube: Oil resistant, synthetic rubber;
Reinforcement: One braid of high tensile steel wire;
Cover: Oil and weather resistant synthetic rubber;
Temperature: -40° F / +212° F, Intermittent use up to 250° F;
Application: Petroleum based hydraulic fluid, water, diesel fuels, lubricating oils, glycol, mineral oils, and more;
Product Description:
SAE 100 R1 technical data

Items number	Hose I.D.	Hose O.D.	Max W.P.		Min B.P		Min.B.R	Weight
	in	mm	Mpa	psi	Mpa	psi	mm	Kg/m
1SN-3	3/16	12.5	25.0	3630	100	14500	90	0.19
1SN-4	1/4	14.1	22.5	3260	90	13050	100	0.23
1SN-5	5/16	15.7	21.5	3120	85	12330	115	0.27
1SN-6	3/8	18.1	18.0	2610	72	10440	125	0.34
1SN-8	1/2	21.4	16.0	2320	64	9280	180	0.43
1SN-10	5/8	24.5	13.0	1890	52	7540	205	0.51
1SN-12	3/4	28.5	10.5	1520	42	6090	240	0.66
1SN-16	1	36.6	8.7	1280	35	5080	300	1.00
1SN-20	1 1/4	44.8	6.3	910	25	3630	420	1.35
1SN-24	1 1/2	52.1	5.0	720	20	2900	500	1.56
1SN-32	2	65.5	4.0	580	16	2320	630	2.20

Quality Control:
Our Equipment:
Our Packaging:
Standrad packaging: Plastic Belt or as your request.
Application:
FAQ 1, Q. What is your terms of packing?
A: Plastic wrap or wrapped according to customer's requirement
2, Q. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
3, Q. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
4, Q. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.
5, Q:what after -sales can we offer?
A: We keep our quality from the material selection to the product itself. Any quality problem after three months, we are responsible for it.
6, Q. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, But you need to pay for shipping.
7, Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
8, Q: How do you make our business long-term and good relationship?
A: We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
