Shutter (Centrifugal Push Pull Type) Cone Fan Axial Flow Air Cooling Air Cooler Blower Ventilation Exhaust Fans High Air Flow Poultry House Livestock Husbandry
Basic Info.
Model NO.
DJF(t)
Usage
Ventilation and Cooling Equipment
Application
Pig Duck Chicken Cow
Power Source
Electric
Certification
ISO9001:2008, CE
Condition
New
Warranty
2 Years
Frame Material
Galvanized Sheet
Drive
Belt Drive
Belt
Japanese Mitsubishi
Motor
Quality Chinese Motor
Bearing
Imported Bearing
Mounted
Wall Mounted
Belt Pulley
High Strength Aluminum-Magnesium Alloy
Power Supply
Electric
Power
0.37-1.1kw
Apply
Poultry House, Greenhouse, Industrial Factory
Name
Djf(T) Shutter(Centrifugal Push Pull) Cone Fan
Fuction
Ventilation Air Cooling
Form
Cone Fan Axial Flow Air Cooling Air Cooler Blower
Transport Package
Standard Paper Carton
Specification
DFJ(t)
Trademark
Yuyun Sanhe
Origin
Shandong China
HS Code
8414809090
Production Capacity
300PCS/Day
Product Description
DJF(t) Series Shutters Cone Fan (Push-Pull Opening System)Product Application: DJF(t) Series Shutter Cone Fan are widely used in Agriculture and industry ventilation and cooling. It is mainly used for animal
husbandry, poultry house, livestock breeding, greenhouse, factory workshop, textile etc.
Technical Parameter:
| Model | Drive | Blades Diameter (mm) | Blades Rotational Speed | Motor Rotational Speed | Air Flow (m³/h) | Noise Decibels (db) | Input Power (W) | Voltage (V) | Frequency (HZ) | Outline Size (H*W*T) (mm) |
| DJF(t)-1380 | Belt | 1270 | 458rpm | 1400rpm | 51020 | ≤64 | 1100 | 220 / 380/ Customized | 50 / 60 | 1380*1380*1430 |
Product Description:
| Frame 1.Material: Hot-dip galvanized sheet 2. Thickness of galvanized layer: 275g/sqm Advantage:Extremely improves the anti-corrosion performance. Longer lifespan and strong anti-oxidation. | |
| Opening System 1.Material: High quality Nylon PA66 2.Guide Rod: 304 stainless steel with special material outside, high strength, no rust, reduce friction. 3.Rivet: 304 stainless steel , wear-resisting, no rust. Advantage: It can keep the shutters open at complete 90 degree to ensure the lowest air resistantce and biggest air volume. | |
| Fan Blades 1. Material : 430 stainless steel, thickness 1.2mm 2. Diameter: 1270mm Advantage: Large air flow, no deformation, no fracture, no dust, attractive and durable. Note: Blade material also have galvanized sheet, aluminum alloy for option | |
| Belt Pulley 1. Material: High strength aluminum-magnesium alloy by die-casting. 2. Blast-sanding treatment, eliminate internal stress to improve its own rigidity and stability Advantage: Light weight, Low vibration ,attractive appearance. | |
| Belt Brand: Mitsuboshi belt (Japanese) Type: A type Advantage: Famous brand, Long service life, maintenance free | |
| Blade Support Base 1.Material: Aluminum Magnesium Alloy. 2. Type: Plug-in connection Advantage: Compare with the traditional welding connection , Our new type Aluminum magnesium alloy base has greatly reduced the friction coefficient, fixed more firmly, avoided | |
| Linking Part 1. Material: Aluminum Alloy 2. Spring: 304 stainless Steel, no deformation ,no rust. Advantage: Light weight, no deformation, long service life. Added with wear-resistant shaft sleeve, reducing friction , ensure the shutters open flexibly. |
About our Company
Shandong Yuyun Sanhe Machinery Co.,Ltd is the biggest and the most professional manufacturer of ventilation equipment in
China,equipped with the most advanced CNC production lines and laser cutting machines, top quality level in the industry.
