Low Price Bench Engine Metal Lathe Precision Cutting Machine (KY280M)
| Negotiable | 1 Set (MOQ) |
Basic Info.
Model NO.
KY280M
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Table
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Motor
0.85kw
Net Weight
200kg
Packing Size
1400*700*680mm
Spindle Bore
26mm
Cross Slide Travel
140mm
Taper of Spindle Bore
Mt4
Range of Spindle Speeds
125~2000rpm
3-Jaw Chuck
1 Set
4-Jaw Chuck(125mm)
1 Set
Swing Over Cross Slide
165mm
Transport Package
Wooden Case
Trademark
KY
Origin
China
Production Capacity
150-200 Sets /Month
Product Description
Features1.Belt driving hobby lathe;
2.V-way bed is hardened and precision ground;
3.Super width bedway gets greater capacity;
4.Spindle is supported by precision tapered roller bearing;
5.Automatic longitudinal feed allows threading;
6.T-slotted cross slide; Adjustable gibs for slideways.
7.Top design of gearbox gets large function etc.
| Specification | |
Model No. | KY280M |
Distance between centers | 700mm |
Swing over bed | 280mm |
Swing over cross slide | 165mm |
Width of bed | 180mm |
Taper of spindle bore | MT4 |
Spindle bore | 26mm |
Number of spindle speeds | 6 |
Range of spindle speeds | 125~2000rpm |
Range of cross feeds | 0.02~0.28mm/r |
Range of longitudinal feeds | 0.07-0.20mm/r |
Range of inch threads | 8-56T.P.I |
Range of metric threads | 0.4-3.5mm |
Top Slide travel | 80mm |
Cross slide travel | 140mm |
Tailstock quill travel | 80mm |
| Taper of tailstock quill | MT2 |
Motor | 0.85KW |
Packing size | 1400*700*680mm |
Net weight | 200kgs |
| Standard Accessories | |
Splash guard | 1 pc |
Chip tray | 1 pc |
3-jaw chuck | 1 set |
Toolbox & tools | 1 set |
| Optional Accessories | |
4-jaw chuck(125mm) | 1 set |
Backplate | 1 pc |
Follow rest | 1 pc |
Steady rest | 1 pc |
Face plate(240mm) | 1 pc |
Live center MT2 | 1 pc |
Collet holder | 1 set |
10mm turning tools(7pcs) | 1 set |
Quick change tool post | 1 set |
Stand | 1 set |
Leadscrew cover | 1 set |
