Pneumatic Vacuum Lift Assist Rubber Block Handling Vacuum Tube Lifter System

Product Description

Product Description
In tire factory,rubber loading is a very tough task for operators.It's 20-40kg,but with additional adhesive force,normally they need 50-80kg to seperate top layer.Vacuum lifter is ideal solution for this application,quick,safe and less effort.

Different from the traditional crane need to hook and up and down buttons to carry items, fast vacuum handling machine will be suction function, up and down control in a control grip, just use the sucker to quickly move to improve the traditional crane operation slow Disadvantages.
Whether it is stacked cartons, moving iron or wood, loading oil drums, placed slate can be used.
Grip from the top or the side, lift high above your head or reach far into pallet racks.
Characteristic
1,Characteristic
Lifting capacity: <270 kg
Lifting speed: 0-1 m/s
Handles: standard / one-hand / flex / extended
Tools: wide selection of tools for various loads
Flexibility: 360-degree rotation
Swing angle240 degrees
Easy to customize
A large range of standardized grippers and accessories, such as swivels, angle joints and quick connections, the lifter is easily adapted to your exact needs.

Serial No.	VEL140-2.5-STD	Max capacity	40kg
Overall Dimension	1330*1060*780mm	Vacuum equipment	Manually operate the control handle to suck and place the workpiece
Control mode	Manually operate the control handle to suck and place the workpiece	Workpiece displacement range	Minimum ground clearance150mm,Highest ground clearance1500mm
Power supply	380VAC±15%	Power input	50Hz ±1Hz
Effective installation height on site	Greater than 4000mm	Operating ambient temperature	-15ºC-70ºC

Features

Suction head assembly •Easy replace •Rotate pad head •Standard handle and flexible handle are optional •Protect workpiece surface	Jib crane limit •Shrinkage or elongation •Achieve vertical displacement
Air tube •Connecting blower to vacuum suctio pad •Pipeline connection •High pressure corrosion resistance •Provide security	Filter •Filter the workpiece surface or impurities • Ensure the service life of vacuum pump

Specification

Type	VEL100	VEL120	VEL140	VEL160	VEL180	VEL200	VEL230	VEL250	VEL300
Capacity(kg)	30	50	60	70	90	120	140	200	300
Tube Length(mm)	2500/4000
Tube Diameter(mm)	100	120	140	160	180	200	230	250	300
Lift Speed(m/s)	Appr 1m/s
Lift Height(mm)	1800/2500					1700/2400		1500/2200
Pump	3Kw/4Kw						4Kw/5.5Kw

Type	VCL50	VCL80	VCL100	VCL120	VCL140
Capacity(kg)	12	20	30	40	50
Tube Diameter(mm)	50	80	100	120	140
Stroke(mm)	1550	1550	1550	1550	1550
Speed(m/s)	0-1	0-1	0-1	0-1	0-1
Power KW	0.9	1.5	1.5	2.2	2.2
Motor Speed r/min	1420	1420	1420	1420	1420

Detail display

1,Air Filter	6,Gantry limit
2,Mounting bracket	7,Gantry
3,Vacuum blower	8,Air hose
4,Silence hood	9,Lift tube assembly
5,Steel Column	10,Suction Foot

Function
Protection against power failure: ensure that the absorbed material will not fall under power failure;
Leakage protection: prevent personal injury caused by leakage, and the vacuum system is well insulated as a whole;
Protection of current overload: that is, to prevent damage to vacuum equipment due to abnormal current or overload;
Stress test, in-plant installation test and other tests to ensure that each set of equipment leaving the factory is safe and qualified.
Safe adsorption, no damage to the surface of material box
Application
For sacks, for cardboard boxes, for wooden sheets, for sheet metal, for drums, for electrical appliances, for cans, for baled waste, glass plate, baggage, for plastic sheets, for wood slabs, for coils, for doors, battery, for stone.
