Agricultural Farm Tractor 4WD 70HP 80HP 90HP 100HP Tractor for Sale

Product Description

Company Profile Leesmax Group company engaged in Agricultural Machinery for over passed decades,Especially focus on Farm Tractors production produce. Have worked together with plenty dealers worldwide and now our brand LeesMax is literally becoming famous brand worldwide market .
LeesMax has a very professor technical team on tractors . We have lots of new creations,Product quality control comes priority in our factory, After years and years development, we have built a chain system from production produce to after sale service. Quality and service are always the core points for us.
Our Tractor Range from 25hp-300hp. Including different series depend on the tractor use. Like Compact Tractors .Farm Tractors . Big farm tractors and even with nuclear Electric tractors. Each series are designed according to the end user actual using environment. Saving energy .and easy operation, Environment protection, and Durable use . Those aspects are all considered in our tractors .
We are now active on searching our right partner worldwide and now we have south America some countries partner and Africa even at East Europe countries .

Product Description 90HP Farm tractor is suitable for a variety of agricultural operations, such as rotary tillage, plowing, trenching, spraying, transportation, etc., and can meet a variety of farmland operation needsEquipped with high-quality diesel engine and advanced fuel injection system, it has the characteristics of low fuel consumption, fast acceleration and strong power, which can improve working efficiency.In addition, it is equipped with large-capacity fuel tank and multiple gears, which can meet the needs of long-term continuous operation and further improve work efficiency.
90HP Tractor is a typical and star models in our farm tractor series . Medium power with proper dimension and along with strong chassis makes it work perfect in small farm especially private farms .Meantime .it could be used also in garden, Orchard ,or as utility tractors .Multi-functional with multi applications.
90HP Farm tractor with PTO design and could work with varies kinds of attachment .For example with Loaders . Backhoe .and forks etc .also properly working with snow plow in special winter season. Air condition. Shelter or canopy . Cabins etc .
Nowadays the 90HP small farm tractors are popular among customers since because its multi functional in medium power range .especially private farm owners ,garden or orchard owners are very much like it.
Product Parameters

Ttactor Parameters	Model		LMX90
	Drive Type		4WD
	Overall Dimensions L*W*H(mm)		4396*2038*2810
	Wheel Track(mm)	Front	1610
		Rear	1620-2020
	Wheel Base(mm)		2195
	Ground Clearance(mm)	Under Front Axle	379
		Under Rear Axle
	RatedTractionForce(N)	In Paddy Fields
		In Dry Fields	20800
	Construction Mass(kg)		3920
	Min.Turning Radius(m)		4.0
	TheoreticalSpeed(Withoutcreeper km/h)	Forward	2.31 ,2.60 ,5.76 ,8.03,10.04 ,15.61 ,24.98,34.85
		Reverse	3.10 ,4.83,7.73 ,10.78
	TheoreticalSpeed(With creeper km/h)	Forward	0.46,0.72,1.15,1.61 ,2.00,3.12,4.99,6.97
		Reverse	0.6,0.97,1.54,2.16
Engine SpecificationsClutch	Model		4MC-T79A (4110)
	Type		4 -cylinder 4-stroke cycle water cooled,vertical
	Rated Power(kw/hp)		66.2(90)
	Rated Speed(rpm)		2300
	Bore*Stroke(mm)		110*135
	Total Displacement		5.13
Drive System	Clutch		Dual Stage
	Gear Box		4*(2+1)*2 Sleeve gear shift
	Main Drive		One pair of spiral bevel gear
	Differential		Bevel gear
	Differential Lock		Sliding pin,foot operated
	Final Transmissions		Planetary reduction gear
TRavelling Mechanism	Tyre	Front	12.4-24
		Rear	16.9-34
	Steering Gear		Hydraulic steering
	Brake		Oil immersed multiplate disc
Working Device	Hydraulic System	Lifting Capacity at610mm Behind Lift Point(kg)	14900
		3-Point Suspension	Category:II
	P.T.O.shaft	Rotating	540/1000 or 720/1000
		Spkine Size	21- Φ35 involute spline

Detailed Photos
