Carpet Felt Mattress Geotextile Needle Punching Machine for Non Woven Production Line
| US$12,500.00-13,600.00 | 1 set (MOQ) |
Basic Info.
Model NO.
HN-360M
Automatic Grade
Semi-Automatic
Certification
CE, ISO9001: 2000
Customized
Customized
Condition
New
After-sales Service
Video Technical Service
GSM
100-1000
Width
as Customer Requirement
Color
Customizable
Power
22kw
Voltage
380V/50Hz
Weight
9000kg
After Warranty Service
Online Surport
Output
360kg/H
Local Service Location
None
Transport Package
Standard Packing
Trademark
NHN
Origin
Shandong Province, China
HS Code
8449001090
Production Capacity
200-300kg/H
Product Description
Middle Speed Needle Punching Machine for Non Woven , Polyester Fabric, Nonwoven Geotextile, Carpet Making Line with CE, ISO Certificate Carding Machine1--Suitable fiber: chemical fiber, such as PET, PP specification: 1.5 ~ 6 d length of 31 ~ 51 mm polyester staple fiber and ES low melting point fiber, glass fiber, aramid fiber, etc.
2-- Product specifications: 40 ~ 900 g / m2 (1 layer)
3-- Production capacity: carding machine output by 220 kg/h (6 d common assessment of chemical fiber as raw materials)
It is suitable for productionof common nonwoven fabric,such as needle punched nonwovens,shoes material,geotextile and etc.Three kinds of jstructural style for this machine:Pre-needling,Upstroke and Down-stroke.
Specification for Needle Punching Loom / Non Woven Fabric Making Machine with CE SGS Certificate
| O | ITEM | DESCRIPTION |
| 1 | Model | HN-360M |
| 2 | Dimension of M/C | L4970W1600H2425(mm) |
| 3 | Weight | 9050kgs/9350kgs |
| 4 | Total power | 22kw |
| 5 | Main motor | 15KW; 3 phase AC power 50Hz/ |
| 6 | Needle density | Depend on the customer's requirements |
| 7 | The average output | 360kg/hour(Working at width 2500mm&300g/m2 under running normal) |
| 8 | Protection | Main motor overload protection |
| 9 | The control mode | Constant power & Inverter control |
| 10 | Working width | 3800mm |
| 11 | Needle plate | High-strength aluminum alloy |
| 12 | Bearing | KOYO/Or according to the customer's requirements |
| 13 | Type of holes | Diameter1.83mm/An inverted cone |
| 18 | Trip of needle | 60 mm /40mm/40mm |
| 19 | Transfer roller | Diameter:168mm/ Chromium plating process/high quality 50# steel |
| 20 | Needle plate | High strength alloys and shock shape /totally 18 mm thickness |
| 21 | The main shaft & other work shaft | Diameter: 80mm/ Dynamic balance and strength strengthening heat treatment/high quality steel |
| 22 | Print Color | Following customer's requirements |
| 23 | The control cabinet and panel | Digital display instrument, and equipped with knob regulator, professional electric schematic diagram |
| 24 | Note | Direction:up first then down/The round-trip distance of the needle can be adaptive adjustment according to the thickness of the raw materials. |
