New Type Magnetic AC Contactors with CE Approval
| US$3.40 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
JLC1-D40N
Phase
1
Main Circuit Rating Voltage
380V
Main Circuit Rating Current
9-95A
Type
Ac Contactors
Installation
DIN Rail
Contact
Silver
Contact Type
New Type
Transport Package
50PCS/CTN
Trademark
CNJUHO
Origin
Zhejiang
HS Code
8536300000
Production Capacity
1000000/Year
Packaging & Delivery
Package Size
9.00cm * 8.00cm * 7.00cm
Package Gross Weight
0.520kg
Product Description
1.Application: JLC1-D series 660V 9-95A AC Contactor is applicable at the line of AC 50/60 Hz, rated voltage up to 660V and rated current up to 95A for remote switch, breaking and frequent starting, controlling the AC motor. Moreover, the contactor can act as the time-delay contactor, reve-rsible contactor, star-delta starter by the accessories addition such as addition of modular auxiliary contact set. Air timedelay head, mechanical interlock mechanism, etc. Moreover, it could act as the electromagnetic starter by the direct plug of the thermal relay. This product conforms to the requirement of IEC60947-4-1& GB14048.4 standards.
2.Main parameter
| Type | Rated insulation voltage(V) | Conventional thermal current(A) | Rated operation current(A) | Control power(kw) | No .of contacts | Remark | ||||
| 220V | 380V | 415V | 440V | 660V | ||||||
| JLC1-0910 0901 | 660 | 20 | 9 | 2.2 | 4 | 4 | 4 | 5.5 | 3P+NO 3P+NC | Installation method 1.with two screws 2.35mm din rail |
| JLC1-1210 1201 | 20 | 12 | 3 | 5.5 | 5.5 | 5.5 | 7.5 | 3P+NO 3P+NC | ||
| JLC1-1810 1801 | 32 | 18 | 4 | 7.5 | 9 | 9 | 9 | 3P+NO 3P+NC | ||
| JLC1-2510 2501 | 40 | 25 | 5.5 | 11 | 11 | 11 | 15 | 3P+NO 3P+NC | ||
| JLC1-3210 3201 | 50 | 32 | 7.5 | 15 | 15 | 15 | 18.5 | 3P+NO 3P+NC | ||
| JLC1-4011 | 60 | 40 | 11 | 18.5 | 22 | 22 | 30 | 3P+NO+NC | Installation method 1.with three screws 2.75mm or 35mm din rail | |
| JLC1-5011 | 80 | 50 | 15 | 22 | 25 | 30 | 33 | |||
| JLC1-6511 | 80 | 65 | 18.5 | 30 | 37 | 37 | 37 | |||
| JLC1-8011 | 125 | 80 | 22 | 37 | 45 | 45 | 45 | |||
| JLC1-9511 | 125 | 95 | 25 | 45 | 45 | 45 | 45 | |||
| Type | JLC1-09 | JLC1-12 | JLC1-18 | JLC1-25 | JLC1-32 | JLC1-40 | JLC1-50 | JLC1-65 | JLC1-80 | JLC1-95 | ||
| Pick-up voltage 50/60Hz(V) | (0.85~ 1.1)Us | (0.85~ 1.1) Us | (0.85~ 1.1)Us | (0.85~ 1.1)Us | (0.85~ 1.1)Us | (0.85~ 1.1)Us | (0.85~ 1.1)Us | (0.85 ~1.1)Us | (0.85~ 1.1)Us | (0.85~ 1.1)Us | ||
| Release voltage 50/60Hz(v) | (0.2~ 0.75)Us | (0.2~ 0.75)Us | (0.2~ 0.75)Us | (0.2~ 0.75)Us | (0.2~ 0.75)Us | (0.2~ 0.75)Us | (0.2~ 0.75)Us | (0.2~ 0.75)Us | (0.2~ 0.75)Us | (0.2~ 0.75)Us | ||
| Coil power | 50Hz 60Hz | Pick-up(VA) | 70 | 70 | 110 | 110 | 110 | 200 | 200 | 200 | 200 | 200 |
| Holding(VA) | 8 | 8 | 11 | 11 | 11 | 20 | 20 | 20 | 20 | 20 | ||
| Pick-up(VA) | 80 | 80 | 115 | 115 | 115 | 200 | 200 | 200 | 200 | 200 | ||
| Holding(VA) | 8 | 8 | 11 | 11 | 11 | 20 | 20 | 20 | 20 | 20 | ||
| Power consumption (W) | 1.8~2.7 | 1.8~2.7 | 3~4 | 3~4 | 3~4 | 6~10 | 6~10 | 6~10 | 6~10 | 6~10 | ||
4.Office and working department:
5.Certificate:
6.shipping:
