Sawdust Grass Briquette Making Machine Biomass Industrial Waste Briquetting Equipment Rdf Briquetting Machine

Product Description

Product Description
Extruder Compression Cube Briquetting Machine Waste Plastic RDF Briquetting Machine
The refuse derived fuel (RDF) forming machine is a system of energy regeneration equipment specifically designed for soft and complex wastes such as domestic waste and industrial solid waste. This series of equipment is particularly suitable for the forming and processing of domestic waste, papermaking waste residue, washing plant waste residue, textile waste, leather waste, rag waste, water plant sludge, industrial sludge, etc. The calorific value of the fuel rod after manufacturing is as high as 5000kcal/kg, with the characteristics of high density, stable calorific value, convenient transportation, easy storage, low secondary pollution, and low emission of toxic substances.
The working principle of the RDF briquetting machine is as follows:
The briquetting machine consists of a machine base, a protective cover, a feed port, a production bin, and a discharge port. The material to be pressed is first crushed, and the length is preferably 30-60mm, and the moisture content is within the range of 15%-25%. The material is fed into the press through the feed conveyor, and the feed port of the briquetting machine evenly disperses the material into the working area between the pressing wheel and the flat die. The rotation of the main shaft drives the pressing wheel to rotate, and the material is forced to be squeezed out of the flat die into blocks and falls from the discharge port.
Raw material and Usage
RDF briquetting machine can process a wide range of raw materials, mainly including the following categories:
RDF briquetting machine can process a wide range of raw materials, mainly including the following categories:
Waste from agricultural and forestry processing: such as sawdust, straw, rice husk, bark, etc.Solid waste raw materials: such as cloth strips, leather, garbage (including urban domestic waste, general industrial solid waste, papermaking waste, clothing factory scraps, waste clothes, industrial sludge, etc.)
RDF briquetting machine can convert these originally waste materials into valuable energy, realize resource recycling, save energy and reduce emissions, and has good economic and social benefits
These are the most common raw materials in our daily life. If you have specific requirements on raw materials, please kindly tell us. Our engineer can give professional advice according to your requirements and design plans for you.
Product Parameters
This is the basic model of our RDF Cube Briquette Press Machine. Our factory manufactures customized machines according to the different requirements of different customers.

Model	Size(m)	power(kw)	output(T/H)	Moisture content of finished product (%)
RDF-45	3.2*2*2.3	75kw	1-1.5	14%-25%
RDF-72	3.5*2*2	110kw	1.5-2.5	14%-25%
RDF-88	4*2.3*2.3	132kw	2-3.5	14%-25%
RDF-120	4.8*2.6*2.5	200kw	4--6	14%-25%

Detailed Photos
Packaging & Shipping
Factory show
Certifications
FAQ
If you have any questions, please feel free to contact us and we can answer you in detail. At the same time, we can provide exclusive customized services based on your different needs.
1.Q: How do we know you are a manufacturer?
A: We can have a video call at any time to show you our actual factory.
2.Q: Can I get a special design for my product?
A: We have our own R&D department to provide customized services to our customers.
3.Q: Are you a factory or a trading company?
A: We are an industry-trade integrated company with more than 20 years of professional experience.
4.Q: How long is your delivery time?
A: Most models are in stock unless customized.
It takes about 20-30 working days for customized equipment.
For 1 or more containers, it takes about 20-30 working days.
5.Q: How long is your warranty period?
A: Within 2 years from the date of leaving the factory, if the parts are faulty or damaged due to quality problems (except wearing parts), we provide these parts for free.
