Professional Manufacturer Maize Wheat Paddy Corn Grain Galvanized Steel Silo Prices

Product Description

Product Description
TSE assembled hopper bottom grain storage silo is made of high quality hot-dip galvanized steel plate pressed into wavy shape by special equipment and made into standard connecting hole, which is connected by high strength bolt.
Grain silos(also called grain storage bins, grain bins) are the steel silos with a cone bottom.Assembly galvanized grain steel silos are erected on the supporting structure to make the delicate products unloading easily through gravity. Grain silos have a smooth wall hopper transition with no steps or flanges to offer the cleanest product discharge from the silo. The stored products inside the silo are isolated from the ground, thereby preventing humidity and allowing the interconnection of silos through tapes, facilitating perfect extraction or dosage.
Structures of Hopper Silo
Hopper silo includes silo roof, manhole, roof handrail, vent, ladder, silo body, stifener, silo door, silo bottom, silo leg.
Main Structure
1. Silo Roof
Grain storage silo roof is to ventilate, protect from rain and wind, and resist wind and snow. The angle of the silo roof is mainly 25° and 30°, and the angle of the silo roof can be customized according to different needs. The silo roof cover is generally made of 1.0 thick galvanized sheet.Our company's cover plate has better sealing and compression resistance. The silo roof cover is equipped with manholes, natural ventilation windows and induced draft fan ports, which can meet the requirements of different functions.
2. Silo Body
The assembled steel plate silo is made of high quality hot-dip galvanized steel plate pressed into wavy shape byspecial equipment and made into standard connecting hole, which is connected by high strength bolt. The thickness distribution of silo plate is set according to strength theory, so that the pressure of silo plate is uniform and consistent. The vertical friction force is borne by the reinforcement which is uniformly distributed in the vertical direction of the silo.The section shape of the reinforcement is Z-shaped column. The connection bolt is equipped with spherical galvanized steel pad, and the screw holeis equipped with aging resistant waterproof gasket Add special waterproof slime strip between warehouse plates.

3. Silo Bottom

Steel cone bottom: steelcone bottom is composed of column, ring beam, conical plate, tension bar and so on. The column is madeofI-beamwhich is made of national standard.l-beamis one of the most widelyusedstee varieties in the design and manufacture of steel structure.It has good structural stability and reliability. The ring beamis pressed with channel steel, which acts as a supporting silo. The function of connecting column and conical bottom plate. The cone bottom plate adopts the full assembly type, and the connecting bolt is the standard part of thenational standard8.8. installation simple and convenient,the whichmakes the cone bottom after installationis beautiful, practical, safe and reliable.

Specification

Model	Volume (m3)	Diameter	Eaves height (m)	Total Height(m)	Weight (T)
3.6×2	33	3.6m	4.985	5.83	1.8
3.6×3	45		6.105	6.95	2.4
3.6×4	56		7.225	8.07	2.9
3.6×5	68		8.345	9.19	3.3
3.6×6	80		9.465	10.31	3.6
3.6×7	92		10.585	11.43	3.8

Door and Footboard Inside Body Bottom
Installation Instructions

*If the client wants to install 10ton-1500ton steel hopper bottom grain silos by themselves, we could offer detailed instruction, and we'll give our quickest response to deal with any question in the process. *We could also send our engineer to supervise the installation process. The client could find local workers for the installation work and our engineer will help them during the process.

*If the client needs, we can send our installation team for the whole installation issue.
Packing & Delivery
TSE factory strictly classifies and packs each parts of silos and silo accessories to ensure the goods are not crushed and damaged during transportation. Also some packing items are made according to customers' requirements. Please check some packaging and shipping photos below for your reference.
Company Profile
Shelley Engineering Co., Ltd. is a company professionally produce and sell grain storage silos. As the main supplier of steel farms and commercial storage bins and silos in China, we offer the most technologically advanced grain dryers in the industry and a large selection of material handling systems, including sweep augers, drying and cleaning systems, commercial bucket elevators and conveyors. Our clients come from mainland China, Ukraine, Poland, Australia, Argentina, Sudan, Vietnam, Korea, Thailand, Iran and Honduras.

We welcome more and more clients to visit our factory. We research and develop a large number of new products every year. "Quality and reputation is the first" is our policy. We welcome friends from all over the world to cooperate with us for a prosperous future. Please feel free to contact us for further information.
Certification and clients
With good quality and service,TSE silos are famous in China and abroad,alsoowned owned many certificates.Some certificates below are just for your reference.
Since 2007, a variety of steel silos and their equipment have been exported to Argentina, Australia the United States, intelligence, Cambodia, Ethiopia, Honduras, Iran, Indonesia, South Korea, Malaysia Myanmar, Pakistan, South Africa, Sudan, Serbia, Thailand, Tanzania, Ukraine, Vietnam, Peru, New Zealand Mexico, the Philippines and Uganda, with frank business philosophy. Excellent product quality and good after-sales service have won extensive praise from domestic and foreign customers and established a long-term cooperative relationship.
FAQ
Q1: What certifications do you have?
A1: ISO certification, BV certification and CE certification.
Q2: What is the export customs code of your product?
A2: 7309000000
Q3. What is your payment method?
A3: 30% advance payment for foreign projects, full delivery.
Q4.Can you do custom design and production?
A4: The selection of prefabricated steel silos is fixed, and the diameter cannot be changed. If other silos such as flour silos, cement silos, and square silos are required, they can be customized for production.
Q5. About installation, how to install? How much is the installation fee?
A5: Abroad: Generally 1-2 people guide the installation, each person 100 dollars per day.
Q6: What materials are used for your steel silo?
A6: At the top of the warehouse, the barrel is a galvanized steel sheet, the cone bottom with a diameter of 4.5m is galvanized
sheet, and the cone bottom with a diameter of 4.5 to 11m is a carbon steel sheet.
Q7:What are the types of steel silos in your company?
A7: We mainly have cone bottom steel silos, Grain Conveyor Belt Bucket Elevator , cement silos and flour silos.
Q8: Can you provide supporting equipment? What can be provided?
A8: Yes. Cleaning equipment includes cleaning screen, vibrating screen, dust removal equipment, and conveying equipment including bucket elevator, chain conveyor, belt conveyor, and screw conveyor.
