US-52 Motor Speed Controller
Product Description
Product Description1. Brief Introduction
The electronic stepless speed controller of AC single-phase induction motor is mainly used to control the single-phase AC induction motor and it adopts the latest electronic control technology. It has the advantages of small size, high precision, wide speed range, low energy consumption, long life and convenient use.
1. Main Technical Parameters
| Model | | US-52 | ||||||
| Appearance | Completed with cable. (Default Length:0.7m) | |||||||
| AC Capacitor | Built-in | |||||||
| Input Voltage | AC 220V±15%，50Hz AC 110V±15%，60Hz(customized) | |||||||
| Work Environment | -10℃～50℃ | |||||||
| Speed Adjustable Range | 90r/min～1400r/min | |||||||
| Matched Motor Power | 6W | 10W | 15W | 25W | 40W | 60W | 90W | |
| Capacitance | 0.8μF | 1μF | 1.5μF | 2μF | 2.5μF | 4μF | 5μF | |
| Matched Motor Power | 120W | 140W | 180W | 200W | 250W | 300W | 400W | |
| Capacitance | 6~7μF | 7~8μF | 8~10μF | 10~12μF | 10~12μF | 12~14μF | 16μF | |
