Cold Rolled Bright High Precision Steel Tube 1020 1035 1045 St52 4140 16mncr5 5120 52100 100gr6 Alloy Bearing Seamless High Carbon Capillary Steel Tube Pipe

Product Description

Product Description Cold-drawn precision seamless steel pipe is a kind of high precision steel pipe material. The main categories are: precision seamless steel pipe, precision hydraulic seamless steel pipe, cold-drawn precision seamless steel pipe, cold-rolled precision seamless steel pipe, high precision seamless steel pipe, precision bright seamless steel pipe.

Product Name	Precision steel pipe/Hot rolled seamless carbon tube/alloy steel pipe/steel tube
Standard	ASTM A106 ,ASTM A53 ,API5L B ,ASTM A179, ASTM A210 ,ANSI B36.10, GB 5310,GB6479,GB9948,GB/T17396GB 3087, GB/T 8162 ,GB/T8163,
Outer Diameter	4-914mm ( Or customized according to customer requirements )
Wall Thickness	1-150mm ( Or customized according to customer requirements )
Length	6m,12m or as per customer's requirements
Packing	In bundles tied with steel stripes
Payment Term	T/T, L/C at sight
Delivery Time	Within 7-60 days after signing the contract or as your requirement
Delivery condition	Beveled or Plain end with varnish/2PP/2PE/3PE/3PP anticorrosive coatingas per clients confirmation ; With or without protecting caps as percustomer's requirements;with FBE internal coating for water steel pipes.
Material	A53(A,B),A106(A,B),Q345,16Mn, 10# 20#,45# S235JR, 1010,1020,1030,1040,1050,ASTMA252 Gr.2,Gr.3; ST37,ST42,ST52;Gr.B,X42,X46,X52,X56,X60,X65,X70, 4140 4120 4130 4142 35CrMo 42CrMo 1033 1320 1330 1527 1340 1345 20Mn 35Mn 40Mn 20Mn2 35Mn2 5115 5120 5135 5140 5145 5150 20Cr 30Cr 35Cr 40Cr 45Cr 5120 20CrMnTi 8620 20CrNiMo 4340 40CrNiMoA 52100 GCr15 27SiMn 9260 60Si2Mn 9255 55Si2Mn 6150 50CrVA 440C 9Cr18Mo 3140 3135 40CrNi etc
Usage	for petroleum/ natural gas pipeline , for conveying water,drainage,coal gas, mineral slurry and other low-middle pressure liquids. Also for chemical industry, building structure,heat-supply and pile driving projects.
Export to	Canada, USA, Argentina,Peru, Chile, Colombia, Brazil, Venezuela,Malaysia, Singapore, the Czech Republic, Australia, Myanmar, Kenya, South Africa, Spain, Italy, France, England, the Netherlands,Belgium, etc
Certificates	API 5L; ISO9001:2000

Chemical Composition (%)

Material	C	Si	Mn	P	S	Cr	Ni	Cu	Mo
ASTM 4119 GB 12CrMo	0.08-0.15	0.17-0.37	0.4-0.7	0.035	0.035	0.4-0.7	0.3	0.3	0.4-0.55
JIS SCM415 GB 15CrMo	0.12-0.18	0.17-0.37	0.4-0.7	0.035	0.035	0.8-1.1	0.3	0.3	0.4-0.55
ASTM 4118 GB 20CrMo	0.17-0.24	0.17-0.37	0.4-0.7	0.035	0.035	0.8-1.1	0.3	0.3	0.15-0.25
ASTM 4130 GB 30CrMo	0.26-0.34	0.17-0.37	0.4-0.7	0.035	0.035	0.8-1.1	0.3	0.3	0.15-0.25
ASTM 4135 GB 35CrMo	0.32-0.4	0.17-0.37	0.4-0.7	0.035	0.035	0.8-1.1	0.3	0.3	0.15-0.25
ASTM 4140 GB 42CrMo	0.38-0.45	0.17-0.37	0.5-0.8	0.035	0.035	0.9-1.2	0.3	0.3	0.15-0.25
ASTM 4142 GB 42CrMnMo	0.4-0.45	0.15-0.35	0.78-1	0.035	0.04	0.8-1.1	0.25	0.35	0.15-0.25

Mechanical property

Material	Diameter of sample d mm	Heat treatment or condition.	Tensile strength σb Mpa	Point of yield σs Mpa	Ratio of elongation δ %	Reduction of section ψ %	hardness HBW	Shock absorption energy KV2 J
ASTM 4119 GB 12CrMo	d=30	Quenching + tempering	≥410	≥265	≥24	≥60	≤179	≥110
JIS SCM415 GB 15CrMo	d=30	Quenching + tempering	≥440	≥295	≥22	≥60	≤179	≥94
ASTM 4118 GB 20CrMo	d=15	Quenching + tempering	≥885	≥685	≥12	≥50	≤197	≥78
ASTM 4130 GB 30CrMo	d=25	Quenching + tempering	≥930	≥785	≥12	≥50	≤229	≥63
ASTM 4135 GB 35CrMo	d=25	Quenching + tempering	≥980	≥835	≥12	≥45	≤229	≥63
ASTM 4140 GB 42CrMo	d=25	Quenching + tempering	≥1080	≥930	≥12	≥45	≤217	≥63

Product specification Specification: outer diameter of hot-rolled pipe is 32~630mm. The wall thickness is 2.5~75mm. The outer diameter of cold rolled (cold drawn) pipe is 5~200mm. The wall thickness is 2.5~12mm.
Appearance quality: the internal and external surfaces of steel pipes shall be free of cracks, folds, folds, delamination, hairlines and scabs. These defects shall be completely removed, and the wall thickness and outer diameter shall not exceed the negative deviation after removal.
Both ends of the steel pipe shall be cut at right angles and the burrs shall be removed. Gas cutting and hot saw cutting are allowed for steel pipes with wall thickness greater than 20mm. The head may not be cut after the agreement between the supplier and the supplier.
product application Seamless pipes are widely used. Seamless pipes for general purposes are rolled by ordinary carbon structural steel, low alloy structural steel or alloy structural steel, with the largest output, and are mainly used as pipes or structural parts for conveying fluid.
Supply is divided into three types according to different purposes: a. Supply according to chemical composition and mechanical properties; B. Supply according to mechanical properties; C. Supply according to hydraulic test. The steel pipes supplied according to category a and b shall also be subjected to hydraulic test if they are used to bear liquid pressure.
There are many kinds of seamless pipes for special purposes, such as boiler seamless pipes, geological seamless pipes and petroleum seamless pipes.
FAQ Q1:who are we?
A:We are based in Shandong, China, start from 2022,sell to North America(60.00%),Western Europe(14.00%),South America(6.00%). There are total about 11-50 people in our office. Q2. how can we guarantee quality? A:Always a pre-production sample before mass production; Always final Inspection before shipment; Q3.what can you buy from us?Which ports are accepted for delivery?
A:Copper,Aluminum,Mould steel, Seamless carbon steel,Precision steel pipe,The steel plate,Alloy steel,Titanium,Custom machine parts.It can be delivered from Qingdao, Tianjin, Shanghai, Guangzhou and other ports. Q4.why should you buy from us not from other suppliers? A:Shandong Meide Import and Export Co., Ltd. has 25 years of production experience. With advanced precision production equipment and modern large warehouses, has a stockpile of 200,000 tons of goods, has a number of long-term stable cooperative customers. Q5.what services can we provide? A:Accepted Delivery Terms: FOB,CFR,CIF,EXW; Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF; Accepted Payment Type: T/T,L/C,D/P D/A,PayPal; Language Spoken:English,Chinese Q6.Can we get the some samples?Any charges? A:Yes,you can get available samples in our stock.Free for real samples,but customers need to pay the freight cost. Q7.How can we get your price ? A:We need below information to quote for you: 1). Product Name 2). Standard 3). Material Grade (Chemical Composition) 4). Dimension 5). Quantity 6). The Drawing for Special Parts
