Hydraulic Roll Grooving Machine for 2 Inch to 16 Inch Ideal for Distributors

Product Description

Product Features
Features of Electric Hydraulic Roll Groover Machine
*RG-6X Electric Hydraulic Roll Grooving Machine, specially crafted for creating roll grooves on lPS steel pipes ranging from 2" to 16" (DN50~DN400) SCH10 to SCH40. Perfect for use in workshops or on-site, this machine is equipped with a motor, hydraulic feeding pump, foot switch, and pipe stand for a complete roll grooving experience.
* The compact large-sized groove machine boasts exceptional versatility and robust performance. Its wide working size range and heavy-duty adjustable bracket make it suitable for varying-sized pipes.
*Specially designed roller set prevents flare on the pipe ends, and eases the installation of the grooved couplings.
*Inbuilt high-performance gear-reducing motor contributes to a compact size and low noise.
*The unique split-type hydraulic system prevents oil leaks and extends service life. Groove depth lock nut ensures high-quality grooves and high efficiency.
Product Parameters

Model:	RG-6X
Suitable materials:	Carbon Steel,SS Pipe
Fabrication Capacity:	2"-16" Pipe SCH10/SCH40
Power supply:	220V/110V
Frequency:	50HZ /60HZ
Max wall thickness:	10mm
Motor power:	1100W
Output speed:	23RPM
Packing gross weight:	170kgs
Packing size:	92*48*87cm

Drive Unit

Item Number		Description			Net weight
912040*		Groove roller for SCH10 Anti-flare (2"~3")			0.45kg
912039*		Groove roller for SCH10 Anti-flare (3½"~6")			0.45kg
912038*		Groove roller for SCH10 Anti-flare (8"~12")			0.45kg
912056*		Groove roller for SCH10 Anti-flare(14"~16")			0.45kg

Standard

Item Number		Description			Net weight
911022		Drive roller 2"~3" (Φ60~Φ89)			1.30kg
911021		Drive roller 3 ½"~6" (Φ101~Φ168)			1.30kg
911020		Drive roller 8"~12" (Φ219~Φ325)			1.40kg
911143		Drive roller 14"~16" (Φ355~Φ426)			1.60kg
912010		Groove roller 2"~3" (Φ60~Φ89)			0.45kg
912009		Groove roller 3 ½"~6" (Φ101~Φ168)			0.45kg
912008		Groove roller 8"~12" (Φ219~Φ325)			0.45kg
912052		Groove roller 14"~16" (Φ355~Φ426)			0.45kg
998026		Foot Switch			1.50kg
998103		Pipe stand for 2"~16" (Φ60~Φ426)			33.0kg
998011		Pipe Stabilizer			2.80kg

Detailed Images
Product Specification
Application
Product Packing
Company Profile
Certification
