Radial Drilling Machine Manufacturer (Z3040X13/1, Z3050X16/1)

Product Description

Product Description

Radial drilling machine manufacturer (Z3040X13/1, Z3050X16/1)
These radial drilling machines of Model ZQ3040× 13 are our main products and sell well at home and abroad because of their best quality and stability. These machines can be used to implement many processes, such as drilling, expanding, reaming, grooving, tapping and etc. On the small and middle parts and even boring if the relevant equipment are available and they are regarded as the idler machining equipments in the machinery and machine work industries.
Radial Drilling Machine
Universal machines
Capable of drilling
Counter-boring reaming,
Spot-facing tapping
Z3035x16 Radial Drilling Machine
1. The radial drilling machine is universal machines, capable of drilling, counter-boring, reaming, spot-facing, tapping and other similar utilities.
2. It is widely used in manufacturing machinery, for processing small and medium size machinery parts and also suitable for being used in repairing.
3. The machine is adopted strengthened type of spindle so that it increases the rigidity of spindle and widens the scope of utility.
4. The spindle has a wide range of turning speed and feeding speed, which make the operation more convenient and more precise.
5. The dimension processed can be set up before working, this allow it stop feeding automatically and has more accuracy
Radial drilling machine radial drilling machine radial drilling machine radial drilling machine radial drilling machine radial drilling machine radial drilling machine radial drilling machine radial drilling machine radial drilling machine Product Parameters

Model Z3040×16/1 Z3050×16/1 Max. Drilling capacity (mm) 40 50 Distance spindle axis to column generating line (mm) 350-1600 350-1600 Diameter of column (mm) 350 350 Spindle taper MT4 MT5 Spindle travel (mm) 315 315 Spindle speeds range (r/min) 25-2000 25-2000 Spindle speeds series 16 16 Range of Spindle feeds (r/min) 0.04-3.2 0.04-3.2 Spindle feeds 16 16 Max. Distance spindle nose to working surface of base (mm) 350-1250 320-1220 Dimension of worktable (mm) 630x500x500 630×500×500 Dimension of base (mm) 2400x1000x200 2400×1000×200 Overall Size (mm) 2500x1060x2650 2500×1060×2650 Power of Main motor (KW) 3 4 G.W/N.W (kg) 3900/3500 3900/3500 Packing dimension (cm) 260x112x260 260x112x260
