Aluminum Truss System Adjustable Height Red Platform Deck Music Staging Outdoor Concert Event Portable Assemble Foldable Performance Stages with Trailer

Product Description

Product	1.portable stage , 2.interlock stage
Size	1.22x1.22m,1.22x2.44m,1x1m,1x2m/4'x4'/4'x8'(Can be customized)
Certification	TUV, CE , ROHS
Material	Aluminum alloy (6061-T6)
Height	16''-24''-32'',24''-32''-40'',32''-40''-48'',40''-48''-52'' 0.4m-0.6m-0.8m,0.6m-0.8m-1.0m,0.8m-1.0m-1.2m,1.0m-1.2m-1.5m,1.5m-1.7m-2.0m
Board thickness	18mm
Platform	glass/ plexiglass/carpet/laminated plywood 18mm/Toughened glass/rubber
Loading capacity	750kgs/m2
Height/Can be customized	A: 0.4-0.8M(1.31-2.62ft) B:0.6-1M(1.97-3.28ft) C:1-1.4m(3.28-4.59ft) D:1.6-2m(5.25-6.56ft)
Brace Tube	50*3mm
Inner Tube	43*3.5mm
Optional accessories	Guardrail, step-stair, ramp, aluminium platform trolley, dolly, skirts

Foshan City ShengSe stage equipment co., LTD., is one of the world's high standards emerging aluminum alloy truss manufacturer, which is located in the manufacturing center of foshan city, guangdong province China , we can supply all kinds of high quality aluminum alloy truss, highly difficulty stage structure, bleachers for indoor and outdoor activities , the column of explosion-proof products, all products have passed CE, TUV certification.
Our advantage is to provide our customers with fast delivery, competitive price, high quality products and 5-year quality assurance. If you are a dealer, please consult with us about reseller programs in order to get a better strategy for your company. We have close relationships with shipping companies that can reduce shipping costs and we can offer hybrid product shipping.
Choosing shengse stage truss can not only get products, but also get better service and better operation mode.
Aluminum alloy is the main material used in mobile assemble stage. Aluminum stage are available in different size, Each size of dance stage can be joined with another via a unique built-in platform connector system. The lightweight frame is made from high quality aluminium alloy, 18mm thick slip- resistant laminated plywood and are beard at 750kg per panel.
Standard size of the aluminum water resistant stage is 1.22 x 1.22m and 1.22 x 2.44m. Stages shapes can be customized according to different occasions. There are round stages and irregular stages. It does not rust, does not corrode, guarantees the appearance, although the cost is low, but the hardness is high. Wedding party stage workable for outdoor and indoor use, stable structure, anti-skid function of the stage board, large stage bearing capacity, very suitable for bar performances,resistant despite of temperature and weather.
Project case:
Feature and Details
(1). Platforms
• stage platform is light, easy to install, convenient for transportation and storage
• Waterproof and anti-skid treatment on the dance stage surface
• Aluminum alloy frame, load-bearing capacity up to 800 KGS/panel
(2). Legs
• Legs can be adjusted at 60, 80 100 and 120cm using interchangeable leg extension tubes.
• Legs are shared between adjacent platforms.
(3). Side Braces
• Lightweight and strong tubular aluminum construction.
• Side Braces are shared between adjacent platforms
How to assemble a stage?
1. Place 4 adjustable bases on the ground
2. Put the 4 legs into the screws of the base
3. Connect every 2 pillars to the stage brace
4. Put the stage board into the stage frame
5. Adjust the whole stage until it is not loose, and then complete
Packaging & Shipping
Packaging: bubble fim or stage trolley.
Delivery: 7-15 days after receiving the deposit, depending on the stage quantities.
Shipping: by sea, air, express or road with competitive price.
Production:
Detail:
Advantages:
10 years experience
More than 10 years experience in truss and stage industry.
The business is widely
The company adheres to the business philosophy of "establishing business with excellence and winning with quality". 99% of its products are mainly exported, and its business covers Europe, America and Southeast Asia.
The manufacturer
We are an independent manufacturer and can give you lower prices.
24-hour customer service
Professional engineers provide technical support to customers.
Sales online
Our professional sales department provides 24-hour online service.
The raw materials
All our raw materials come from listed companies.
The high quality
Our perfect quality control system ensures the high quality of each product.
After-sales service
5 years after-sales service.
Quality control
Test all products before delivery.
Q&A: 1.Q: What certificate do ShengSe Stage have?
A: TUV / CE/ ROHS certification.
2.Q: What is the terms of payment?
A: We accept Western Union, T/T, 50% of invoice value as deposit,50% balance paid before shipment, and some others.
3.Q: Where is the loading port?
A: Ports in Guangzhou or Ports in Shenzhen.
4.Q: How does your factory do regarding quality control?
A: We control products quality under the instruction of national standards.
5.Q: What is your packaging?
A: Air bubble film or carton or flight case.
6.Q: How long the deliver time?
A: General it is about 5-7 working days.
7.Q: Do you accept OEM order?
A: Yes, we welcome OEM order as well.
8.Q: Do you accept customized logo order?
A: Yes, we can make logo on the product for clients. After-sales service:
1. Professional engineers and application specialists respond effectively to your requests
2. Follow up the case and record the whole process. The solution will provide 24-hour service
3. At the same time, problem complaints will be reported to the QC department, QC will find defects from the deparment who is responsible for the responsibility
4. Collect and record customer feedback to help customers use the product smoothly
Warranty period:
1. Lifetime warranty.
2. any problem caused by our side within one year from the date of shipment, we will provide free spare parts for repairment.
3. After one year, we can provide spare parts, but the user should pay relevant fees, including spare parts cost, delivery cost, etc.
