Continuous Orange Apple Juice Clarifier Stacked Centrifuge

Product Description

Product descriptions from the supplier The disc centrifuge is a liquid-solid (or liquid-liquid solid) separation by utilizing the principle that the components of different densities (or emulsions) have different densities in the centrifugal force field. Disc separator is a kind of 2/3 phase sedimentation disc centrifuge, which is used to separate hard-to-separate materials
(Including mineral oil, gasoline, diesel, dairy products, vegetable oil, beverage, separation and purification of chemical products etc).

Item/Model	DHZ270	DHZ400	DHZ500
Bowl Diameter(mm)	265	400	500
Bowl Speed(r/min.)	7300	6525	5900
Bowl Factor	7900	9290	10300
Throughput(L/H)	600-1500	3000-6000	5000-10000
Discharge time and Interval	Discharge time can be adjusted from 0.1~0.9 second, and discharge time interval can be adjusted from 1~240 minutes according to the raw material
Motor(kw)	4	11	18.5
Motor Speed	1460
Turn on time (minute)	5~8
Stopped time (without brake)	≤40minute
Input pressure (mpa)	0~0.1
Output pressure(mpa)	0~0.3
Working water pressure	0.2≤p≤0.45
Noise (dB)	≤73
Max. vibrate(mm/s)	1.5
Size(mm)	950×800×1100	1500*900*1500	1805*1400*1120
Weight(kg)	550	1000	1500

Structure and principle:
The bowl rotates at a high speed round the main axis, driven by a motor through hydraulic coupling and screw gear pair. stock liquid flows from the upper feeding pipe into the bowl's bottom and then will be separated through holes of disc seat. by the action of centrifugal force field, heavy liquid flows along the inner wall of discs to the inner wall of the bowl, after up flowing along them, it will be discharged by the heavy liquid pump, the light liquid will be done by the light liquid pump, which flows along the inner wall of discs into centre pipe and then up to high liquid outlet. the larger solid phase particles left will sedimentate on the bowl's wall and then will be discharged, controlled by the sliding bowl, out of the sediment outlet. Feature of products 1. The drum has undergone precise dynamic balance verification, ensuring smooth operation, low vibration, and low noise during operation.
2. All components in contact with materials are made of stainless steel material, which can effectively reduce the corrosive effect of separated materials and meet food hygiene requirements.
3. Equipped with a stationary light and heavy phase discharge centripetal pump. The separated light and heavy two-phase materials are respectively output from the light and heavy phases at the top of the drum to the central pump, with the light phase entering the next process.
4. The power transmission adopts a hydraulic coupling and a pair of spiral speed increasing gears, which use liquid to transmit power, ensuring stable speed increase and overload protection.
5. Equipped with automatic control cabinet. It is composed of industrial computers and machine overload automatic protectors, with a high degree of automation, strong adaptability to process adjustment, convenient adjustment, and can greatly reduce the operating intensity of workers.
Why Choose Us? Main machine shape All auto control; Auto feeding, discharging, cleaning, CIP etc. Food and GMP standard design; Testing before delivery; Customized design; Explosion proof motor optional; Motor brand optional; Similar function with German brand centrifuge. Multi application, food and chemical.
Customized drum Special steel material, long lifetime; Inner customized, better separating effect; Famous brand; High rotating speed; Manufacturing material can be customized. PLC control Siemens PLC control ; Schneider Electric parts; All auto control system; Electric diagram offer; Customized explosion proof;
Application field:
1.) Mineral oil industry: purification of fuel oil and lubricating oil such as ship main engine;disc centrifuge 2.)Dairy Industry: clarification, purification degreasing of fresmilk;disc Separator centrifuge 3.)Vegetable oil industry: purification and clarification of palm oil, degumming, soaping, dehydration and dewaxing of refined vegetable oil.;disc Separator centrifuge 4.)Beverage Products Industry: clarification of beer, fruit juice, beverage, etc., disc Separator centrifuge 5.) Starch Industry: Concentration and grading of starch pulp;disc Separator centrifuge 6.)Industry: purification or clarification in the extraction process of antibiotics and biochemical ,disc Separator centrifuge 7.) Chemical Industry: purification or clarification of chemical raw materials;disc Separator centrifuge 8. )Lanolin industry: extract and purify lanolin from wool washing sewage;disc Separator centrifuge 9.) Latex industry: Purify and concentrate natural rubber emulsion;disc Separator centrifuge Specification:
