Ja Solar Panel Solar 16bb Mono Photovoltaic Panels N-Type Bifacial

Product Description

Product Description
JAM72D42 LB 615-640W
Cell: MonoNo. of cells: 144(6×24)Rated Maximum Power(Pmax): 640WMaximum Efficiency: 22.9%Junction Box: IP68, 3 diodesMaximum System Voltage: 1500V DCOperating Temperature: -40ºC~+85ºCConnectors: MC4 EVO2A/ QC4.10-351

MECHANICAL PARAMETERS		OPERATING CONDITIONS
Cell	Mono	Maximum System Voltage	1500V DC
Weight	34.6kg	Operating Temperature	-40°C~+85°C
Dimensions	2465±2mmx1134±2mmx30±1mm	Maximum Series Fuse Rating	30A
Cable Cross Section Size	4mm²(EC), 12 AWG	Maximum Static Load, Front*	5400Pa(112 lb/ft?)
No. of cells	144(6x24)	Maximum Static Load, Back*	2400Pa(50 lb/ft?)
Junction Box	IP68, 3 diodes	NOCT	45±2°C
Connector	QC 4.10-351/ MC4-EVO2A	Bifaciality**	80%±10%
Cable Length (Including Connector)	Portrait: 300mm(+)/400mm(-) Landscape:1500mm(+)/1500mm(-)	Safety Class	Class ll
Front Glass/Back Glass	2.0mm/2.0mm	Fire Performance	Type 29/Class C
Packaging Configuration	36pcs/Pallet,576pcs/40HQ Container

ELECTRICAL PARAMETERS AT STC
TYPE	JAM72D42 615/LB	JAM72D42 620/LB	JAM72D42 625/LB	JAM72D42 630/LB	JAM72D42 635/LB	JAM72D42 640/LB
Rated Maximum Power(Pmax) [W]	615	620	625	630	635	640
Open Circuit Voltage (Voc) [V]	51.87	52.07	52.27	52.47	52.67	52.87
Maximum Power Voltage(Vmp) [V]	43.31	43.51	43.71	43.90	44.10	44.29
Short Circuit Current(lsc) [A]	15.06	15.11	15.16	15.21	15.26	15.31
Maximum Power Current(lmp) [A]	14.20	14.25	14.30	14.35	14.40	14.45
Module Efficiency [%]	22.0	22.2	22.4	22.5	22.7	22.9
Power Tolerance	0~+3%
Temperature Coefficient of lsc(α_lsc)	+0.045%/°C
Temperature Coefficient of Voc (β_Voc)	-0.250%/°C
Temperature Coefficient of Pmax(γ_Pmp)	-0.290%/C
STC	lrradiance 1000w/m², cell temperature 25°C, AM1.5G
Remark: Electrical data in this catalog do not refer to a single module and they are not part of the offer. They only serve for comparison among different module types.

ELECTRICAL CHARACTERISTICS WITH 10% SOLAR IRRADIATION RATIO
TYPE	JAM72D42 615/LB	JAM72D42 620/LB	JAM72D42 625/LB	JAM72D42 630/LB	JAM72D42 635/LB	JAM72D42 640/LB
Rated Maximum Power(Pmax) [W]	664	670	675	680	686	691
Open Circuit Voltage (Voc) [V]	51.87	52.07	52.27	52.47	52.67	52.87
Maximum Power Voltage(Vmp) [V]	43.31	43.51	43.71	43.90	44.10	44.29
Short Circuit Current(lsc) [A]	16.26	16.32	16.37	16.43	16.48	16.53
Maximum Power Current(lmp) [A]	15.34	15.39	15.44	15.50	15.55	15.61
Irradiation Ratio (rear/front)	10%
* For Nextracker installations, maximum static load please take compatibility approve letter between JA Solar and Nextracker for reference. **Bifaciality=Pmax, rear/Rated Pmax, front

Grade A Material
Our Factory
To ensure high quality, Sail Solar continuously invest high quality production equipment.
We have LEAD stringer, MITSUBISHI electric laminator and ETSUN automatic lamination equipment etc. Automatic production line, fast delivery and cost saving.
Strict QC System100% Cells Sorting
Ensure Color and Power No Difference.
Ensure high yields,consistent performance and durability,
First of 52 steps strict quality control and inspection process.
100% Inspection
Before and After Lamination.
Most stringent acceptance criteria and tightest tolerance
Intelligent alarm and stop mechanism in case of any deviation or errors 100% EL Testing
Before and Following LaminationEnsure "Zero" micro crack monitoring before final Inspection, Continuous line monitoring and video photo record for each cell andpanel.
Packaging & Shipping
Packing Details : In carton on pallet or wooden box, OEM with your logo is available
Delivery Details : 5-7 working days
Projects
Payment

Payment Term	T/T	EXW	30% T/T in advance, paid the balance before shipment
		FOB
		CFR(CNF)	30% T/T in advance, paid the balance against copy of B/L
		CIF
	L/C	L/C amount above 50,000 usd, we can accept L/C at sight
	Western Union	Amount Lower than 5000usd
