Internal Grinding Machine CNC Centerless Grinder Boring Honing Machine Mk2110b

Product Description

1.The machine bed adopts the casting piece with the features of good rigidity and small deformation.
2.The headstock is fixed on the feed slide for achieving work feed. The gri. wheel reciprocation is also used.
3.Work feed guideway and gri. wheel worktable guidaway adopt the crossed roller type.
4.Work feed can be performed by the servo motor through the coupling via high-precision ball leadscrew pair.
5.The oil cylinder is used to drive the worktable to achieve gap elimination and rapid advance reciprocation of workpiece.
6.Table reciprocation movement can be achieved by mechanical oscillation which its reci. speed is adjusted by the freq.-conversion speed regulator.
7.Cartridge-type work spindle is used. The high-precision matched spindle bearing is adopted with the features of high rotating accuracy and good reliability.
8.Super-wide worktable and feed slide are used, thus improving good rigidity.
9.It's totally enclosed with guards to prevent swarfs from splashing.
10.The rear-mounted electrical cabinet and front-mounted control cabinet are also used. The heat-exchanger in the electrical cabinet is also provided.
11.The special fixture can also be designed according to the machined workparts.
12.Mitsubishi PLC control system a& servo unit is adopted. Other control system can also be selected for special order.
13.The grinding cooling system is adopted. Independent coolant tank can be used for cooling the electric spindle with water-break protection.
14.According to requirements of user, this machine can be designed as below: One-axis CNC feed + hyd. gap elm. + mechanical osci. reciprocation Machine model: MK2110B/1 Two-axis CNC feed + CNC reciprocation Machine model: MK2110B
