Baoji Torno 660mm Swing Dia. Over Machine Bed 105mm Spindle Bore Horizontal Lathe

Product Description

Features:


It has the characteristics of high precision, high power, high rigidity, excellent manufacturing, and complete functions. Its main components and structures have been optimized and well designed. Now it has been verified by many users. This model of lathe has obvious advantages: high accuracy, high efficiency and high reliability. The application of the main drive frequency conversion speed regulation system has not only been highly favored by users, but also second to none in the industry, and is now in mass production.

DESCRIPTION	UNIT	CS6266B/Cx3000
CAPACITY
Max Swing dia. over the bed	mm	Ø660
Max swing dia. over cross slide	mm	420
Max swing dia. over gap	mm	870
Effective length in gap	mm	240
Max workpiece length	mm	3000
Max turning length	mm	2950
SPINDLE
Spindle Bore diameter	mm	B: Ø82; C: Ø105
Taper of spindle bore		No.6; opt: Ø90 1:20; opt: Ø 113 1:20
Type of spindle nose		(B & C series) ISO 702/III No.6 ISO 702/II No.8
Spindle speeds	r/min	24- 9-1600r/min. (C)12 36-1600r/min
FEEDS AND THREADS
Max travel of upper toolpost	mm	145
Max travel of lower toolpost	mm	310
Tool section	mm	25x25
X axis federate	m/min	50Hz:1.9; 60Hz:2.3
Z-axis federate	m/min	50Hz:4.5; 60Hz:5.4
Metric threads	mm	0.5-224mm,48kinds; 1-14mm, 22 kinds
Inch threads	t.p.i	72-1/8tpi,46kinds; 28-2tpi, 25 kinds
Module threads	mm	0.5-112,42kinds; 0.5-7mm,18 kinds
Diametric pitch threads	dp	56-1/4DP, 24kinds; 56-4DP,24kinds
TAILSTOCK
Diameter of quill	mm	Ø 75
Max travel of quill	mm	150
Taper of quill		Morse No.5
MOTOR
Main motor power	KW	7.5
Rapid travers motor power	KW	0.3
Coolant pump motor power	KW	0.12

ACCESSORIES
RIGHT HANDWHEEL(ON APRON), 3, 4-JAW CHUCK AND ADAPTER, 4-WAY TOOL POST, STEAD REST 120-260MM for CS6266(C), FOLLOW REST, FACE PLATE, DIRVE PLATE, FOOT BRAKE, FULL LENGTH SPLASH GUARD, LONGITUDINAL MECHANICAL STOP, HALOGEN LIGHT. CHUCK COVER, TOOL POST COVER

Packing & Shipment
1. Before packing, every metal part of the machine will be painted with a layer of anti-rust and water-proof oil to avoid possible rust during transportation.
2. Plastic cover will be used to wrapp around machine to enhance corrosion prevention.
3. Export standard fumigated wooden cases or polywood cases are used for packing.
4. Steel wire, wedges ect. will be used to fix the machine in the container to avoid packing cases leaning
or moving during transportation.
Expo Cases
FAQ
1. MOQ
1 set
.
2. DELIVERY TIME
It depends on the machine and model you choose. Mostly 2 months - 4months. All machines are 100% new and not used.

3. PAYMENT TERM
T/T 30% down payment when order ,70% balance payment before shipment .
4. WARRANTY PERIOD
13 months from the date of B/L, during the warranty period, daily damage parts will be supplied freely, the after sale service will be done by dealers . After warranty period, the spare parts will be supplied at factory price.
