C6240f Hot Sale High Precision Saddle Lathe Machine with CE Certificate

Product Description

C6240F hot sale high precision saddle live center lathe with CE certificate
Product Description
Series For Wholesales
♦ Bed rail grinding, high precision.
♦ Headstock gear precision grinding low noise
♦ Electric system is reliable and safe
♦ Foot brake / electromagnetic brake can be amounted when needed, and color at user's option.
♦ Carriage optional:left hand,right hand.
♦ Big slide can be: common, fast forward or tapered structure.
♦ Three bars can be Metric or British system.
♦ Customizable C6160F/C6260F

	MODEL	C6236F	C6240F	C6250F
CAPACITIES	Max. Swing over bed	360mm	400mm	500mm
	Max. Swing over slide	190mm	230mm	310mm
	Workpiece cutting length	750mm,1000mm,1500mm,2000mm,3000mm
	Max. Swing over gap	520mm	560mm	660mm
	Effective length of gap	160mm	130mm	130mm
	Bed width	360mm
HEADSTOCK	Spindle hole	Φ52mm
	Spindle nose	IS0-C6
	Spindle taper	MT6/1:20
	Spindle speeds(number)	28-1800rpm(12 steps)
FEEDS	Metric threads range(kinds)	0.5-14mm(21 kinds)
	Inch threads range(kinds)	2.5-72 inch(30 kinds)
	Module threads range(kinds)	0.25-7mm(17 kinds)
CARRIAGE	Cross slide travel	220mm
	Compound rest travel	120mm
	Cross-section size of tool shank	20*20mm
TAILSTOCK	Taper of tailstock sleeve	MT4/MT5
	Diameter of tailstock sleeve	65mm/75mm
	Travel of tailstock sleeve	130mm
MOTOR	Main motor power	4kw/5.5kw/7.5kw
	Cooling pump motor	0.125kw
	Rapid motor	0.12kw
Center Distance		750mm 2120*1150*1800mm
		1000mm 2420*1150*1800mm
		1500mm 2920*1150*1800mm
		2000mm 3420*1150*1800mm
		3000mm 4420*1150*1800mm
Center Distance		750mm 1350/1700 1400/1750 1500/1850
		1000mm 1450/1800 1500/1850 1600/1950
		1500mm 1600/1950 1650/2000 1750/2100
		2000mm 1700/2100 1800/2200 1900/2300
		3000mm 2000/2500 2100/2600 2200/2750

Details Display

Packing shipping
For machine: usually by sea;
For documents: by international express, eg. DHL,TNT or EMS.
For packing :Free fumigation plywood packaging steel base
our service
1. Technical support online service provided.
2. Technical files service provided.
3. Machine operation video provided
4. On-site training service provided.
5.Spare parts replacement and repair service provided.
6 All of the questions will be replied within 8 hours
7. If you need to develop products with your own specification, we can help you to work it out.
8. Always be honest, never lie to customer, and never declare anything we don't have Company Profile
Since 1996,20 years' history for machine tool manufacturing
10 years' history for export
Total 2 manufacturing bases in china
Sino-germany technology cooperation
Production of 8 categories, more than 130 kinds of products
Set up design&research center at TAIWAN
Exported to total 48 countries in the world covered most areas
One-stop shopping for nearly all other types' machine tools
FAQ
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
6: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
We want to know:
1.What's your Industrial Voltage?
2.We strongly suggest you to tell us size, material of your workpiece for our evaluation, if possible, better to send us workpiece drawing, so that we can recommend you most suitable model!
3.If need CIF Price, please kindly tell us the port of destination.
