Mini Lathe Machine

Mini Lathe Machine

US$2,360.00-2,800.00 1 set (MOQ)

Basic Info.

Model NO.
G1324
Type
Horizontal Lathe
Guide Rail
Horizontal Guide Rail
Tool Holder
Single-tool Holder CNC Lathe
Power Source
Electric
Automatic Grade
Automatic
Setting Mode
Table
Precision
Precision
Certification
ISO 9001
Condition
New
N.W/G.W
300/350
Swing Dia. Over Bed
330
Distance Between Centers
610mm/1000mm
Transport Package
Veneer Box and by Sea
Specification
1325x585x1030
Trademark
xing
Origin
China
HS Code
84589900
Production Capacity
700-1000

Product Description

Main features:
1)Has the purposes of turning, milling, drilling, boring & thread-cutting.
2)DC brushless motor, big torque at low speed, infinitely variable speed.
3)Power-driven for table in milling.
4)Cam clamping chuck.
5)Lengthened table.
6)Has the devices of safety interlock & an overload safety.
7)Lengthened drilling/milling box, 360° rotation in veritical plane.
Standard configuration:
3-jaw chuck, drilling chuck, drill taper stock, center, drawing
bar, exchange gear, tools, etc.
Special configuration:
Stand, steady rest, follow rest, milling chuck, milling cutter, live
center, etc.

SPECIFICATIONS G1324 G1340
Swing dia. over bed 330mm(13") 330mm(13")
Swing dia. over table 190mm(7.5") 190mm(7.5")
Distance between centers 610mm (24") 1000mm(40")
Spindle bore 28mm (1.1") 28mm (1.1")
Spindle speed 50~3000r/min 50~3000r/min
Longitudinal stroke 510mm ( 20") 890mm( 35")
Cross stroke 185mm (7.3") 185mm(7.3")
Small toolpost stroke 70mm (2.75") 70mm(2.75")
Metric pitch/grade 0.35~6.5mm/24 0.35~6.5mm/24
Inch pitch/grade 7~52T.P.I./21 7~52T.P.I./21
Longitudinal feed/grade 0.067~0.5mm/r/21 0.067~0.5mm/r/21
Cross feed/grade 0.021~0.157mm/r/21 0.021~0.157mm/r/21
Milling-drilling spindle taper MT3 (R8) MT3 (R8)
Milling-drilling shaft stroke 127mm(5") 127mm(5")
Milling-drilling box stroke 110mm(4.33") 110mm(4.33")
Table size 450×170mm (17.7x6.7") 450×170mm(17.7x6.7")
Drilling dia. 24mm (0.95") 24mm(0.95")
Power of motor 1.1kw 1.1kw
Overall dimensions of machine 1325×585×1030mm 1705×585×1030mm
Case dimensions of machine 1260x570x1100mm 1640x570x1100mm
N.W/G.W 300/350kg 330/380kg
Package Venner case Venner case

Product Details:


Packing and Delivery
Special:

company information
Shandong Linyi Jinxing Machine Tool Co., Ltd.was founded in 1965 and locates in Shandong Linyi high-new technology development zone. It is national high-new technology enterprise on patents in Shandong province. It owns provincial level high-tech R&D center.
It mainly deals with the development,manufacturing and sales of machine tools. It has the yearly capacity of manufacturing vertical machinning center,CNC milling machine,CNC lathe,common machine tool,multi-purpose machines etc.over ten thousands sets.
The company has passed through ISO9001 Quality System Certificate and owns self-operation right of import and export. some products have passed through CE certificate.Its products are sold widely at home and over more than 30 countries and districts abroad such as USA,Canada,Germany ,Italy,Hungary,Australia,South Africa,Korea and Japan,etc.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Technology support :
Professional after-sales service team:
We can Provide Spare parts replacement and repair service
Competitive price:
We can recommend the most suitable machine according to your budget and customer needs, and give you a favorable price.
OEM Accepted:
We can produce design as your requied.please contact us.
We have strict quality control system.please believe our quality.
MOQ: 1 set .
Terms of Payment: T/T (30% in advance and delivery on 100%)
If you have any questions ,please feel free to contact us.
Shandong Linyi Jinxing Machine Tool Co.,Ltd.
