Catc HEPA Filter Air Purifier Replacement Filter Element Air Filtration H13 H14 H15

Product Description

Product Description All heating and cooling air duct systems naturally collect dust and contaminants. Clean rooms, such as those used in the electronics, pharmaceutical, and medical industries, require a controlled environment free of dust, airborne particles, and other contaminants. Ultra low particulate air (ULPA) filters and high efficiency particulate air (HEPA) filters are used in commercial air filtration systems to trap extremely small particulate contaminants.
ULPA filters trap more and smaller particulate matter than HEPA filters. ULPA filters are 99.999% effective at removing submicron particulate matter of 0.12-micron diameter or larger.Mini pleat design ensures low resistance to airflow.Seamless sealing technology.Uniform air flow, high efficiency,low resistance.Anti-aging technology,long service life. FeaturesApplication:Mainly used in terminal filtration of electronics, Bio,pharmaceutical industries,hospitals,,FFU,Laminar flow devices,and other clean room equipments.
Frame: Anodized aluminum profile
Media: Ultra fine glass fiber
Media guard:Aluminium mesh/Painting fished expanded mesh
Fiber class according to EN1822:2009 : U16/U15
Fiber class according to ASHRAE 52.2-2007:MERV20
Efficiency:99.99995%,99.9995% at 0.12μm
(DOP/PAO Counting method)
Maximum temperature: 70ºC
Maximum relative humidity: 100%
Customized size: Available Detailed Photos
Product Parameters

Model	Actual size W×H×D(mm)	Air flow (m³/h)	Initial pressure drop(Pa)	Final pressure drop(Pa)
CATC48470	484×484×70	370	167Pa Face velocity 0.5m/sec	340Pa *Proposed value
CATC63070	630×630×70	650
CATC57070	570×1170×70	775	117Pa Face velocity 0.35m/sec	240Pa *Based on FFU performance
CATC117070	1170×1170×70	1640
CATC48490	484×484×90	370	139Pa Face velocity 0.5m/sec	280Pa *Proposed value
CATC63090	630×630×90	650
CATC57090	570×1170×90	775	98Pa Face velocity 0.35m/sec	200Pa *Based on FFU performance
CATC117090	1170×1170×90	1640

Certifications
Packaging & Shipping
Company Profile Shujiajing Environmental Technology Co., Ltd., established in 2020 , the company has evolved into a comprehensive large-scale private enterprise, specializing in environmental technology and electromechanical equipment. Our expertise includes technical development and transfer, design and construction of water conservancy and hydropower projects, electromechanical engineering, and water treatment projects. Additionally, we engage in research, processing, and sales of aluminum profiles, hardware products, automation equipment, and accessories (excluding plastic products). Our diverse portfolio also encompasses new materials, electromechanical equipment, electronic components, fiberglass products, construction materials, and environmental protection materials. Our products have gained international recognition, being exported to countries such as South Korea and Vietnam.
After Sales ServiceFAQ
Q1: Do you provide samples?
A2: Yes, free sample can be provided but customer needs to pay for the shipping costs.
Q2: Can the product be customized?
A2: Yes, customized filters are available.
Q3: How long is the delivery time?
A4: It depends on the order quantity. Usually it takes about 7 to 15 working days after receiving your deposit.
