High Efficient Capillary Rheometer In Testing Equipment

Product Description

Product Description
Product DescriptionNLW400 Capillary Rheometer is dedicated to measuring high polymer flow properties and viscosity characteristics of the thermoplastic material, for the production and development of important scientific information and a detailed analysis report is to study the rheological properties of the polymer materials, the shear rate viscosity changes, quality management, product development, testing and other work, an indispensable instrument.Features★ Whole machine adopts the aluminum alloy structure, the appearance is more beautiful, the stability is stronger, and is easier to transport and install. Strong function, high precision, simple operation, procedures powerful, beautiful appearance★ The high frequency of data acquisition (greater than 100PPS) can more accurately record the transformation points under different states of the material, and will not leak out the key material state transformation points, and accurately calculate the apparent viscosity at different shear rates★ Can achieve a variety of data curve superposition; a variety of curvilinear form coordinates display★ The loading device of the instrument is reasonably, the high precision pressure sensor is used to collect data, and the traditional load sensor is cancelled. The double closed loop of software and hardware is used to realize the stepless adjustment of speed and load. Two kinds of loading and control system can be used manually and automatically, which is convenient, fast and accurate★ Adopt advanced high temperature and pressure load, with high-end technology servo motor and perfect operation software★ With the programming, design, control, analysis and data storage functions. It is ideal for rheology control.★ Design of multi-channel heating, accurate temperature control, uniform distribution★ Through the PLC precise control system, desk type computer, to analysis of capital stock.★ Can set 20 different stages of the shear rate and shear stress for sampling point★ Operation mode - constant speed mode or constant pressure mode★ Desktop type Capillary rheometer, the head of the machine can be rotated flexibly to facilitate the cleaning of the boreSpecificationModelNLW400A NLW400BMax test capacity10KNMax test temperature400℃Heating rate1-10℃/minTemperature resolution0.1℃Pressure range1-50MpaPrecision of pressure measurement± 0.5%FSPressure resolution0.1MpaSpeed range0.001-500mm/minPrecision of deformation measurement± 0.5%FSCylinder diameter12mmCylinder length200mmSize of die(1) 5/0.5-L= 5 mm , D = 0.5 mm ; (2) 10/1-L= 10 mm , D = 1 mm;(3) 20/1-L= 20 mm ,D= 1 mm; (4)30/1-L= 30 mm , D= 1 mm ;(5) 20/2-L= 20 mm , D= 2 mm; [select any two of them]Test modeConstant speed or constant pressureDimension600×410×2100mmPower supply220V 50Hz 100WPacking & DeliveryPackagingSize600×410×2100mmPackaging Details1. The equipment is covered with film is protect it from water vapour during the trip. 2. The box is filled with foam to protect the equipment from impact. 3. Exported wooden box made from plywood, don't need fumigated. PaymentPayment ItemT/TEXW 30% T/T in advance, paid the balance before shipmentFOBCFR(C&F) 30% T/T in advance,paid the balance against copy of B/LCIF30% T/T in advance, paid the balance before shipmentFOBCFR(C&F) 30% T/T in advance,paid the balance against copy of B/LCIFL/CL/C amount above 50,000 usd, we can accept L/C at sightWest UnionAmount lower than 50,000usdDelivery Time7~10 days after receiving payment for one containerOur CompanyHistorySince 1982 with more than 20 years' experienceWarrantyTwo Year Warranty for whole productTrainingVideo and user manual for trainingOnsite serviceInstallation and training service is availableTesting serviceFree sample testing before order is availableLead time15 working days lead time for most productContacting Us ERIC QINWebsiteMobile Phone+86 188 5510 5986Whatsapp+86 188 5510 5986Skype eric-qlkWechat+86 188 5510 5986
