Automatic 9 cavity plastic water bottle high speed blow moulding machine

Product Description

Product Description
Automatic 9 cavity plastic water bottle high speed blow moulding machineProduct DescriptionBrief introduction of water bottle blow moulding machine:"All-electric version" high-speed linear automatic blow molding machine is developed and produced by our company using advanced bottle making technology. The single-cavity capacity of the blow molding machine reaches 1800-1400 bottles/hour/cavity (≤0.60L bottle), which can meet the needs of customers with high production capacity. It is mainly used for the blowing of PET container bottles (cold blow mold) for drinking water, beverages, food, cosmetics, medicine, etc. This machine is equipped with automatic bottle preforms loading system, high degree of automation, stable performance and high speed. Separation of man and machine, reducing pollution sources and ensuring product quality. Working Principle of Blow Molding Machine (Nine Cavity)1. "Electric version" high-speed linear automatic PET bottle blowing machine consists of automatic preform unscrambling mechanism, automatic preform loading mechanism, heating system, stepping system, mold clamping and blowing mechanism, bottle taking mechanism and man-machine interface part of the composition.(1) The preforms of unscrambling machine arranges the messy preform tubes into nine groups and arranges them neatly, and sends them to the preform delivery mechanism waiting for the loading preform.(2) There is a detection photoelectric switch in the mechanism preform unscrambling machine, which controls the action of the preform delivery motor and separation preform cylinder: it is also the detection point of the preform channel shortage alarm.(3) The preform loading mechanism organizes the preforms neatly, arranged in a group of nine, and then drives the manipulator jaws on the heating head via the rotary cylinder.(4)The heating system heats the preforms inserted by the preform delivery mechanism at a constant temperature.(5) The heating channel of the preform is completed by 1 channels of 5 sets of heating boxes and 10 layers of infrared heating lamps. The temperature of each layer of the tubes is individually controlled and adjusted, and is completed by the man-machine interface.(6) After the preform heating step and the preform are heated, the mold is pushed forward, and the rotary servo motor is used to drive the step track to drive the preform to accurately position the operation.(7) There are 9 photoelectric tube detection photoelectric switches before the preform tube enters the blowing mechanism, which is to determine whether the preform tube also determines the action of the blowing machine.(8) After the positioning operation of the propulsion system is completed, the bottle preform blowing mechanism stretches and inflates the preform which has been heated at a high temperature.(9) The bottle taking mechanism is driven by the rotary cylinder to drive the manipulator jaws to remove the blown finished bottle from the heating head.(10) There is a travel switch after the bottle taking mechanism, which is the alarm and the emergency stop device after the bottle taking mechanism leaks the bottle.(11) The human-machine interface, that is, the touch screen, is the working platform of the operator's operating machine, and is divided into an operation interface, a monitoring interface, a parameter input interface, an alarm interface, and the like.(12) One blower machine equipped with a high pressure gas storage tank (60L) with a pressure of 40kg, one (27L), one low pressure gas storage tank (60L) with a pressure of 10kg, one (27L); The supply of gas is stable. It is equipped with an air filtration system to ensure that the air source is clean. Machine show PET Prefrom from preform loader into blowing machine Heating lamp in the heating oven Details show Main technical parameter:ModelItemGD-A4GD-A6GD-A9ProductivityDepend on bottle design3200-4000pcs/h4000-5500pcs/h12000-13000pcs/hBottle specificationVolume0.1-2.0L0.1-2.0L0.1-2.0LBody diameter≤100mm≤100mm≤100mmHeight≤300mm≤300mm≤300mmNeck diameter28mm-38mm28mm-38mm28mm-38mmMoldCavity469Mold thickness240mm240mm240mmMain machine powerRated power49kw73kw98kwUsage power13kw25kw45-65kwAir systemHP air compressor2.0m3/min 3.0MPa6.0m3/min 3.0MPa6.0m3/min 4.0MPaLP air compressor1.6m3/min 1.0MPa2.0m3/min 1.0MPa4.0m3/min 4.0MPaAir tank0.6m3 3.0MPa1.0m3 3.0MPa2.0m3 4.0MPaAir dryer2.0m3/min 3.0MPa6.0m3/min 3.0MPa10.0m3/min 4.0MPaCooling water systemWater chiller3HP3HP15HPMain blowing machineSize(L*W*H)1900*1860*1930mm4100*2400*1930mm6160*4000*3300mmWeight3600kg4200kg9000kgPreform unscramblerSize(L*W*H)2000*950*2480mm2000*950*2480mm4960*2110*2500mmWeight250kg250kg8000kg Our engineer will make 2D bottle desginCompany Information Project casesOur exhibitionWorkshop deatilsOur teamOur ServicesCustomer's service:1.Grandee company can provide turn-key project for you, only you have any idea to start beverage factory plant.2. Grandee company have professional design team, our engineer can draw bottle samples and flow chart of workshop for you .3. Grandee company give you the best quotation for all kinds of beverage production, only you can tell me which kind of drink you want to product, what is your capacity(how many bottles one hour) what is you bottlematerial, pet or glass,etc After service:1. We send the engineers to help installing, commissioning and training, the engineers start from our factory area.2. We supply below necessary documents with the machine: a. Machine layout b. Electricity diagram c. Machine certificate d. General manual book/maintenance book3. After one year guarantee, the seller provides payable spare parts and technician’s VISITING maintenance service.FAQQ1: How to find suitable machine or complete beverage production line?A1: Looking for beverage filling machine in www.grandeemachine.en.china.cn •Enquiry: Contact us by email, phone call, fax, Instant Messenger (Trade manager, Skype, WhatsApp, Wechat) and let us know your requirements • Discussion: Specify the items and what are you exactly looking for. Q2: Are you a trading company or a manufactory?A2: We are the manufacture of water/beverage filling machine and water treatment system over 10 years.We just not only sell drinking water machines and other related equipment , Quality is our culture. We have rich experienced engineers with technicians working team , providing good and after-sales service term , professional salesman terms . Q3: Do you have technical support after we purchased your machines?A3: We will arrange our professional technical to go aboard to your factory, they will help you and teach you how to install and maintenance the machines which you purchased. Or help you to fix machine when it has problems. Q4: If you buy our machines, can you offer us wear-out spare pats?A4: We provide our high quality machine 2 years guarantee , and we will also offer you 2 years wear-out spare parts for free. Once your machines broken or doesn't work within 2 years and you can't solve it, firstly, we will try to help you to find problems from your words description by phone or other communication tolls. Secondly, if the phone solutions still not work, our engineers will go to your factory to solve it. Meanwhile, they will teach you the related experiences for fixing.
