CE Hx220HD Hx210HD Th225c 20 21 21.5 22ton Hydraulic Crawler Excavator Large Digger Eaxcavator in Algeria
Basic Info.
Model NO.
TH225C
Type
Crawler Excavator
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Bucket
Shovel
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
1.0~1.5m³
Size
Medium-Sized
Certification
CE, ISO9001: 2000, EPA/EAC
Condition
New
Brand
Famous Brand
Max. Power
195kw@2000rpm
Operating Weight
33000kg
Dimension
11220*3670*3390mm
Specification
33000kg
Origin
China
HS Code
8429521200
Production Capacity
300units/Month
Product Description
Product DescriptionCE Hx220HD Hx210HD TH225C 20 21 21.5 22ton Hydraulic Crawler Excavator Large Digger Eaxcavator in Algeria
TH225C excavator is equipped with a new air-conditioning system, which optimizes the air-conditioning ducts, provides stronger cooling effect, and more reasonable air volume distribution. The air conditioner evaporator enables in-car cleaning and maintenance, making cleaning easier. Configurations such as delayed extinguishing of lights when shutting down at night, one-touch switching of front and back display screens, and rear cameras ensure driving safety.
Application: Constructions works
Operating Weight: 21200kg
Engine: 6B5.9
Bucket Capacity: 1.0 m³
Main pump: K3V112DT, 2x218L/min
Main control valve: HVE270B, 350kgf/cm2
Rotary motor: M5X130CHB, 260kgf/cm2
Travelling motor: TM40VD, 350kgf/cm2
Dimensions: 9600x2800x3045mm
Product Parameters
| Model | TH225C |
| Engine model | B5.9-C |
| Rated power | 112kw/1950rpm |
| Max.torque | 614N·M/1500rpm |
| Displacement | 5.9 L |
| Emission standard | Tier 2 |
| Operation Range | |
| Operating weight | 22800 kg |
| Max. digging height | 10075mm |
| Max. dumping height | 7165 mm |
| Max. digging depth | 6515 mm |
| Max. vertical digging depth | 5795 mm |
| Max. digging reach | 9865 mm |
| Min. swing radius | 2970 mm |
| Dimensions | |
| Overall length | 9615 mm |
| Overall width | 3180 mm |
| Overall height | 3045 mm |
| Tail swing radius | 2925 mm |
| Min. ground clearance | 466 mm |
| Counterweight ground clearance | 1055 mm |
| Undercarriage/Working Device | |
| Std. track shoe width | 800 mm |
| Bucket capacity | 1.05 m³ |
| Carrier roller(per side) | 2 |
| Track roller(per side) | 9 |
| Track gauge | 2380 mm |
| Boom length | 5700 mm |
| Arm length | 2925 mm |
| Performance | |
| Travel speed | 3.2/4.7 km/h |
| Gradeability | 35° |
| Ground pressure | 35.3 kPa |
| Tractive force | 203 kN |
| Bucket digging force | 127 kN |
| Arm digging force | 92.5 kN |
| Service Refill Capacities | |
| Fuel tank | 330 L |
| Engine coolant | 28 L |
| Engine oil | 20 L |
| Hydraulic tank | 270/400 L |
| Hydraulic System | |
| Type | Negative flow Hydraulic system with Variable Displacement Piston Pump |
| Pump flow | 2X218L/min |
| Swing System | |
| Swing speed | 0-10.2r/min |
