Qk1319 High Quality CNC Lathe Machine Tools

Product Description

Main Features
1. high rigidity, high stability, smooth discharge, guarantee a long-term accuracy.
2.Low vibration,long work life of tools, save the cost of tools.
3.More choice of configuration, including counter spindle, VDI power turret, double turret,
CNC Lathe Features
Hot Sale Small CNC Turning Center Slant Bed cnc Lathe TCK46A 1.45 degree slant bed cnc lathe 2.High accuracy Taiwan linear guideways 3.Chip conveying capacity is large and convenient ,customer could choose chip conveying in the right or in the back 4.Spindle unit has two types ,the heavy duty cutting type and the high speed type. 5.The first one is suitable for bearing and gear processing . 6.The second type is suitable for high speed and jhigh precision processing. 7.Customers could choose any type of them 8.Screw pre-stretching structure 9.Gang type tool post 10.Optional turret

Model and specifications	QK1319
Guideway width	550 mm
Max. swing over bed	630mm
Max. swing over carriage	350mm
Hole through spindle	200mm
Max. processing Pipe diameter	196mm
Max. workpiece length	1500/3000 mm
Range of spindle speed changes (r/min)	24~300
Tool post style	Vertical 4 Stations
Knife rest translocation time(S)	3S
Repeated positioning accuracy	±0.002
Processing workpiece precision	IT7
Bed quenching hardness	HRC52
Workpiece surface roughness	Ra1.6
Power of main motor	7.5/11kw
NC system	Guangtai130IT/Guangshu980TA2 (According to customer's requirement )
Chuck	500 3-jaw

FAQ: 1.Q: Which trade term I can choose? A: You can choose FOB,FCA 2.Q: How can I get quotation from you?
A: You can make the inquiry online on made-in-china, or send email to us. It is better if you can tell what is your detailed request information. We will reply to you within 24 hours on work days, and within 48 hours on holiday. 3.Q: how can I make the payment?
A: You can pay by T/T . You can also pay to my company business bank account. 4.Q:What is your delivery time ? A:The delivery depends on different machines with different configurations. Please contact us to confirm it is in stock or not.
