Jt-960V High Accuracy Mitsubishi Controller Spindle Customized Automatic CNC Lathe Machine
| US$34,000.00-45,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
JT-960V
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Point to Point Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Condition
New
Precision
High Precision
Net Weight
6300kg
Tool Libranes
21 Arm Type Tool Libranes
Standard System
Mitsubishi M80
Transport Package
Seaworthy Packing
Specification
2700*2400*2750mm
Trademark
JT
Origin
China
HS Code
8458110000
Production Capacity
1500sets/Year
Product Description
Product Parameters
| ITEM | UNIT | JT-960V | |
| Workbench | Workbench size | mm | 1060*580 |
| Worktable load-bearing capacity | kg | 800 | |
| T-slot width (width x spacing x number of slots) | mm | 18*110*5 | |
| Trip | X-axis travel | mm | 900 |
| Y-axis travel | mm | 600 | |
| Z-axis travel | mm | 680 | |
| Distance from spindle end face to workbench | mm | 110-790 | |
| Distance from spindle center to Z-axis rail surface | mm | 610 | |
| Principal axis | Speed range | rpm | 12000 |
| Main spindle power (continuous/30 minute rated) | kw | 7.5/11 | |
| Spindle torque(rated for continuous/15minutes) | Nm | 35.8/70 | |
| Slope of spindle inner hole | BT40 | ||
| Transmission mode | Direct-type | ||
| Feed | X-axis rapid displacement | m/min | 30 |
| Y-axis rapid displacement | m/min | 30 | |
| Z-axis rapid displacement | m/min | 30 | |
| Feed rate | mm/min | 15000 | |
| Automatic tool change system | Tool magazine capacity | set | 24 |
| Maximum tool outer diameter (when fully loaded) | mm | 80 | |
| Expanding the diameter of the hollow blade | mm | 150 | |
| Maximum tool length | mm | 300 | |
| Maximum tool weight | kg | 8 | |
| Tool change time (knife to knife) | sec | 24 | |
| Precision VD13441 (JISB6338) | Positioning accuracy | mm | P0.01(±0.004/300) |
| Repetitive accuracy | mm | Ps0.008(±0.003) | |
| Other | Electricity dernad | Kva | 25 |
| Barometric pressure demand (minimum) | kg/cm² | 6 | |
| Cuting fluid capacity | liter | 300 | |
| Machine footprint | mm(approximately) | 2700*2400 | |
| Machine height | mm(approximately) | 2750 | |
| Machine weight | kg(approximately) | 6300 | |
