High Quality Dhy500 Disc Stack Centrifuge for Evening Primrose Oil Extraction

Product Description

Product Description High quality DHY500 disc stack centrifuge for Evening Primrose Oil extraction
Principle
Disc centrifuge uses centrifugal force to separate microbial cells. It has a set of discs inside, and when the centrifuge rotates at high speed, the microbial cell mixture is introduced into the centrifuge drum. Due to the effect of centrifugal force, microbial cells and other components (such as culture medium, cell debris, etc.) will produce different radial movement speeds between discs due to density differences. Microbial cells with higher density will move towards the edge of the drum, while components with lower density (such as clear liquid) will gather towards the center or other specific areas to achieve separation.
Main Features:
The disc centrifuge is a liquid-solid (or liquid-liquid solid) separation by utilizing the principle that the components of different densities (or emulsions) have different densities in the centrifugal force field.Disc separator is a kind of 2/3 phase sedimentation disc centrifuge, which is used to separate hard-to-separate materials(Including mineral oil, gasoline, diesel, dairy products, vegetable oil, beverage, separation and purification of chemical products etc).Disk stack centrifuge is high-speed cen.trifuge for the mechanical separationand clarification of mixtures comprisingsolids and liquids. These machines canbe used in a wide range of applications.Due to their special design, disk stackcentrifuges work at a higher rotationspeed than other centrifuges such asdecanters. As a result, the centrifugaacceleration(g-force)generated by adisk stack centrifuge is significantlymore powerful than in decanter centri-fuges. Moreover, the disks included pro-vide a large clarifying area. Thus, it ispossible to separate ultra fine solid parti-cles from a liquid and to separate liquidmixtures in an efficient way.
Benefits : * High reliability drive train system.* Bowl design with superior separation performance and with good response to discharge loads.* Pilot valve regulates total/partial discharge of solids* Super partial discharge(option) minimizes liquid loss and maximizes thickening of solid* Full automation possible with PLC automatic control panel.Scope of supply :* One set separator * One set PLC control box * One set tools * Electromagnetic flow-meter* Sight glass
Structure and Principle There are two types Disc Stack Separator one is 3 Phase Disc Stack Separator,one is 2 Phase Disc Stack Separator,more details you can check the following information .3 phase disc stack separator is a high-speed, stable, sealed, efficient, and automatic slag discharge 3 phase separation equipment. It is widely used for liquid, liquid, solid 3-phase separation or liquid-liquid separation.The 2-phase solid-liquid separation disc separator has only one liquid discharge port and one slag discharge port, while the 3-phase disc separator has two liquid discharge ports and one slag discharge port, which can separate two liquids with different specific gravity at the same time. It can also discharge solid phase materials. Compared with the 3 phase decanter centrifuge, the 3 phase disc separator has larger rotation speed and G force. The 3 phase decanter centrifuge usually has a separation factor of about 3000G, while the 3 phase disc stack separator G force is up to 12000G. Therefore, the 3 phase disc separator can more thoroughly separate liquids with different specific gravity and the liquid phase discharged is more clarified. However, compared to 3 phase decanter centrifuges, 3 phase disc separator is more used to separate materials containing fine particles, with less solids content. So before entering the 3 phase disc separator, the material can separated by the decanter centrifuge for pre-stage separation to reduce the solids content and remove big particles.

Equipment characteristics: 1.It can separate substances with extremely small density differences.The rotating drum of the disc centrifuge has a high rotational speed and can generate a strong centrifugal force with a high separation factor. This enables it to quickly and effectively separate substances with extremely small density differences. For mixtures that are difficult to separate by conventional filtration or sedimentation methods, such as emulsions and fine particle suspensions, it has excellent separation effects.2.High production efficiency. Due to its efficient separation ability, the residence time of materials in the disc centrifuge is very short and the production efficiency is high.3.Good clarification effect.The disc centrifuge has a precise disc design. The discs inside the disc centrifuge have a very small spacing and are arranged in a conical shape, forming numerous narrow channels. When materials enter the centrifuge, under the action of centrifugal force, solid particles or impurities will quickly move along the lower surface of the discs to the edge of the rotating drum and deposit there. The clarified liquid can smoothly flow through the channels between the discs to the center of the rotating drum, thus realizing efficient separation of solids and liquids and obtaining highly clarified liquid.4.It can continuously and automatically discharge slag. It can continuously discharge the solid impurities deposited on the edge of the rotating drum without stopping the machine.5.Durable and Robust Construction:Crafted from premium 304/316L stainless steel and Duplex Steel, this centrifuge is built to withstand the rigors of industrial use, ensuring long-lasting durability and dependability.6.Comprehensive after-sales support:This product comes with a 1-year warranty on core components (including PLC, bearing, and motor) and a 1-year warranty for the entire machinery, ensuring customers receive timely assistance in addressing any issues that may arise during use.
Detials photos: Application 1.) Mineral oil industry: purification of fuel oil and lubricating oil such as ship main engine;2.)Dairy Industry: clarification, purification degreasing of fresh milk;3.)Vegetable oil industry: purification and clarification of palm oil, degumming, soaping, dehydration and dewaxing of refined vegetable oil.;4.)Beverage Products Industry: clarification of beer, fruit juice, beverage, etc., 5.) Starch Industry: Concentration and grading of starch pulp;6.)Industry: purification or clarification in the extraction process of antibiotics and biochemical ,7.) Chemical Industry: purification or clarification of chemical raw materials;8. )Lanolin industry: extract and purify lanolin from wool washing sewage;9.) Latex industry: Purify and concentrate natural rubber emulsion;
Microbial fermentation industry: In the process of producing antibiotics, enzymes, amino acids, and other products through microbial fermentation, disc centrifuges can be used to separate microbial cells from the fermentation broth. For example, in the production of penicillin, after fermentation, the microbial cells that produce penicillin are separated from the fermentation broth by a disc centrifuge. On the one hand, the cells can be collected for subsequent research (such as cell metabolism studies), and on the other hand, the supernatant can be further processed to extract penicillin.
Environmental Microbiology: Disc centrifuges can help separate microbial cells from wastewater or contaminated environmental samples. Researchers can understand the pollution level and microbial community structure of wastewater by analyzing these microbial cells. For example, in sewage treatment plants, disc centrifuges can be used to separate microbial cells from activated sludge for monitoring and optimizing the sewage treatment process.
Product Parameters

Model	Capacity (L/h)	Drum diameter (mm)	Drum speed (r/min)	Separation factor	Power (KW)	Weight (kg)	Dimension (mm X mm X mm)
DHC230	1500	230	6930	6170	2.2	240	850X625X985
DHC300	2000	300	7200	6950	4	550	865X645X1100
DHC 360	3000	360	6500	7000	5.5	650	900X600X1150
DHC400	4000	400	6500	7500	7.5	750	1100X1050X1250
DHC500	8000	500	5800	8500	18.5	1200	1250X1000X1550

Model	Bowl speed (rpm)	Capacity (L/H)	Outline size (L*W*H)	Weight (kg)	Inlet pressure (Mpa)	Disc stack thickness (mm)	Vibration at nominal speed (mm/s)	Motor power (KW)	Voltage (v)	Material
DHY	7070	1000-1500L/H	1500×1130×1500	750	0.05	0.1	4.5	7.5	380V	All the contact parts made by SS304

Notes:For more information, please contact us
★ The actual processing capacity depends on the particle size and the specific application
All contact material can made by SS304 ,SS316L , duplex steel .
And the machine surface can be painted or full stainless steel . depend on customized
Factory show : Packaging & Shipping
Company Profile Liaoning Koen Machinery Co.,Ltd ,We are the professional manufacturer of centrifuge machinery, separation equipment over 30 years,we have 4 factory which located in Shanghai , Jinhua ,Yixing and Liaoyang city . Our president was designed and manufactured China First Tubular Centrifuge .Our factory covers an area of 58, 700 square meters, including 38, 600 square meters of workshop area, 4, 000 square meters of office building and 2100 square meters of science and technology building. The company has been committed to the production of domestic advanced disc and decanter centrifuges, with an annual output of 4000 sets of production capacity. The company also specializing in provide with the whole set of technology and equipment. we have professional technology team to design, research and development for customer according to customer's requirements, and have high standard production process control. Our international trade department can supply the whole project service. Our aim is providing you efficiently solution and superior after-service. We have overseas after-sales service department in Taiwan ,Russia ,Korea ,USA,Thailand,Malaysia and Indonesia . We sincerely hope YOU are our next customers! Exported country:At present, our products have been exported to the United States, Belgium, Canada, Australia, Greece, Bolivia, Peru, Saint Lucia, Israel, Malaysia, Indonesia, Philippines, Sri Lanka, Vietnam, South Korea, India, Denmark, Russia, Georgia, Jordan, Bangladeshi, Tailand, Ethiopia, Finland, Spain, Japan, Colombia, Romania and so on more than 30 countries.
FAQ Q1.What's your advantage? Why we choose you?A:1) More than 50 years experience of centrifuge & separator production and R&D.We have the most professional techniques and team. More advantage in price.2)Great production capacity Sustainable Supply . According to customer requirements, We support the customized include package.3)We use Internationally renowned brand Inverter and PLC . Good quality materials and the best production processQ2.What's the Payment?A: T/T, Western Union, L/C, Ali Pay, etcQ3.Are you a factory or trading company?A:We are a professional manufacturer. We are warmly welcome clients from worldwide to visit our factory and cooperate with us.Q4.How long is the warranty period ?A:18 months after install .
