DS Tech G13 Pro Series Electronic Whiteboard Android 13 86 85 75 65 inch Interactive Panel Displays With EDLA

Product Description

DS Tech G13 Pro Series Electronic Whiteboard Android 13 86 85 75 65 inch Interactive Panel Displays With EDLA For ClassroomProduct DescriptionPowered by the advanced Android 13.0 operating system and equipped with either 8GB RAM and a spacious 128GB SSD or 16GB RAM paired with an expansive 256GB SSD, this interactive flat panel ensures lightning-fast performance and ample storage for educational content, apps, and multimedia resources. At its core, a potent combination of Quad-core ARM Cortex-A78 and Quad-core Cortex-A55 processors delivers unparalleled speed, efficiency, and reliability, enabling educators to effortlessly engage students with interactive lessons, multimedia presentations, and collaborative learning experiences. With its intuitive interface, vibrant display, and robust features, our Interactive Flat Panel with EDLA for Classroom is the ideal solution for modern educational institutions seeking to enhance teaching effectiveness, foster student engagement, and inspire lifelong learning.
DS TECH G13 Interactive Flat Panels, available in sizes of 86, 75, and 65 inches, revolutionizing classroom engagement with cutting-edge technology. Our panels are equipped with Google EDLA (Enterprise Devices Licensing Agreement), a groundbreaking program introduced by Google in late 2022. This initiative is tailored to assist solution providers, like DS TECH, in offering devices embedded with Google Mobile Services, ensuring seamless integration and access to a myriad of educational resources and applications.NFC Functions
In addition to its advanced features, the G13 Pro interactive touch panel offers NFC functionality, providing users with versatile options for enhanced security and streamlined administrative management. With NFC-enabled cards and mobile devices, users can effortlessly lock the screen, safeguard sensitive data, and execute various administrative tasks. This intuitive system not only ensures data protection but also facilitates convenient access control and efficient management, empowering users to optimize their workflow with ease and confidence.
Wireless screen mirroring
DS Tech's wireless screen mirroring functionality allows for the simultaneous projection of laptop screens, mobile phones, and tablets onto the electronic whiteboard, accommodating up to nine devices. This hassle-free solution eliminates the need for cables and projectors, delivering unparalleled convenience for presentations in classrooms and meeting rooms alike.48Megapixel AI camera and 8 arrays microphone
The built-in 48-megapixel camera boasts advanced features including auto people capture and AI tracking, ensuring seamless and effortless capture of meeting participants. Coupled with the 8-array microphone setup, which employs noise reduction technology, our device delivers unparalleled audio clarity, making every meeting a smooth and productive experience. With these powerful tools at your disposal, communication and collaboration reach new heights.
Louder speaker
enhanced audio immersion with the G13 Digital Whiteboards featuring robust speaker capabilities. Boasting dual speakers with a combined power of 2x12W, complemented by a potent 20W bass amplifier, these whiteboards deliver rich, immersive sound quality. Whether in classrooms, boardrooms, or collaborative spaces, enjoy crystal-clear audio that amplifies your presentations and enriches your multimedia experiences to captivate audiences like never before.
Detailed Photos
Product Parameters

Product Parameter
Model	DSY-65G13	DSY-75G13	DSY-85G13	DSY-86G13	DSY-98G13
Backlight	DLED
Active display size (diagonal)	65"	75"	85"	86"	98"
Aspect Ratio	16:9
Display dimension (mm)	1428.48 (H) x 803.52(V)	1650.24 (H) x 928.26(V)	1872 (H) x 1053(V)	1895.04(H)×1065.96(V)	2158.85 (H) x 1214.35(V)
Dynamic Contrast Ratio	4000:1(typ.)	4000:1(typ.)	4000:1(typ.)	4000:1(typ.)	1200:1(typ.)
Resolution	3840*2160 (4K)
Colors	8 bit / 1.07 billion colors
Brightness	320cd/m2	350cd/m2	350cd/m2	350cd/m2	350cd/m2
Response time	8ms	8ms	6 ms	8 ms	8 ms
View Angle	178°, 178°
Pixel pitch -mm (H×V)	0.124×0.372 mm (H×V)	0.4298 x 0.4298mm (H×V)	0.4875 x 0.4875 mm (H×V)	0.4935 x 0.4935mm(H×V)	0.5622 x 0.5622mm (H×V)
Panel life expentance	≥30000 hrs
LCD quality	Grade A+
OPS Slot	Yes
Power consumption	Maximun< 220W, Standby Mode<0.5W	Maximun< 300W, Standby Mode<0.5W	Maximun< 350W, Standby Mode<0.5W	<=420W,Standby Mode<0.5W	Maximun<450W, Standby Mode<0.5W
Power voltage	100V - 240VAC, 50/60Hz
VESA hole site	4-M8 screw hole 400 x 200 mm	4-M8 screw hole 600 x 300 mm	4-M8 screw hole 600 x 400 mm	4-M8 hole site 400*200mm	4-M10crew hole 800*400 + 400 mm

Android System (Default)
System configuration	Android13.0 RAM 8G+ SSD 128G /RAM 16G+SSD 256G Quad core ARM Cortex-A78 + Quad core Cortex- A55
Interface Inputs / Outputs	Input interface : RS232*1 MIC*1 RJ45*2 TF CARD*1 DP*1 Touch USB*2;TYPE-C;HDMI*2; USB3.0*2 USB2.0*1; Output interface: Audio*1;COAXIAL(RCA)*1;HDMI*1;TYPE-C. Front interface: USB3.0*2;HDMI*1;USB TOUCH *1;Type-C*1;
NFC Module	Maximum communication rate	1M bps
	Working Frequency	13.56MHz
	Working distance	Less than 5cm
Front button	Menu;Home;Eye-care;Recorder;Screenshot;VOL+/-;Power Button On/Off;Reset
Audio
Speaker	Sound chanel	2.1
	power	2×12W+20W
Video (NOTE: ONLY G13 PRO series have camera and microphone, G13series do not have camera and mic)
Camera	pixel	48Megapixel
	quantity	1
	position	Top border
Micphone	Pick up	0~8m
	quantity	8 array high-resolution microphones
Touch Screen Parameter
Glass surface	4 mm Anti-glare Tempered glass
Technology	IR touch
Touch supported	20 points touch
Writing tools	finger or any opaque object
Positioning accuracy	1 mm
Response Time	≤ 5ms
Power supply	USB ; DC 5.0±5%
Minimum touch object	≥φ3MM
Software	Yes
Touch Life Expectancy	≥ 60 million times
Packing Details
Package list	Remote controller*1, Power cable 1.5m*1, HDMI cable 3m*1,USB touch cable 3m*1,Triangle fine pen *2;Wall Mount Bracket*1; User manual(pdf)*1, WIFI antenna *4

Certifications
Packaging & Shipping
FAQ
Are you a factory?Yes, we are a factory locates in Shenzhen China. We mainly do OEM orders of interactive touch panels and LCD screens. Our factory have about 125 workers( peak season about 180 person). R&D team and engineers 13 persons.Can you send a sample to me before bulk order?Yes. DS supports sample order. and low MOQ 1 piece, clients can buy 1 set to test before place bulk order. Can you make the touch panels according to our specifications?Yes. DS is an interactive touch panel OEM factory, and provides OEM services including: LOGO (brands) customization, functions customization, software customization and package customization. Clients can send the specification and requirements to our sales team, our R&D engineers will evaluation possibilities and provide a solution for clients. What's the available size of interactive flat panel? Interactive flat panels standard size 55" 65" 75" 85" 86" and 98". Do the classroom interactive flat panels have free Apps for teaching? DS interactive flat panels for school all are pre-installed with free apps, including digital whiteboard, wireless miracast, WPS, Chrome,Firefox browser, Zoom, Skype, Microsoft Meeting etc. Can I have my brand logo labeled? Yes. We provide free Logo on smart board with MOQ 10pcs. And we will set your logo as booting logo when turning on the machine.What accessories are included in the package? DS interactive flat panel standard package include: interactive screen*1, wall-mount bracket*1, power cord*1, Remote control*1, WIFI antenna, HDMI cable*1, Touch USB cable*1. And optional parts (which is charged additionally) include: Mobile trolley, wireless screen dongle, OPS slot-in computer. Our AdvantagesWhy should I buy from us?Firstly, top industry suppliers: DS's raw materials are sourced from top brands in the industry including LG, SAMSUNG, AUO large size LCD panel companies, Powerboard all sourced from Magmeet, Motherboard include Amlogic, MTK,CVTE,etc. Secondly, strict quality control: DS strictly abides by 5 quality inspection processes, from pre-production raw material factory inspection, warehousing inspection, to in-production quality inspection, complete machine acceptance inspection, and pre-shipment inspection. The strict multiple quality inspection processes ensure that each machine delivered to customers is a 100% qualified product.Third, good technical support and after-sale support. Any of issues raised by clients will be acted within 24 hours. Solutions are given to clients with max 48 hours.4 reasons to buy from DS tech.Fourthly, DS has more than 10 years in OEM service. And we received good comments from our customers.
