Vmc-850 CNC Vertical Machining Center Metal Lathe CNC Milling Machine
| US$34,300.00-34,600.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Vmc-850
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Point to Point Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
High-End CNC Machine Tools
Certification
CE, ISO 9001
Condition
New
Precision
High Precision
Net Weight
5000kg
Standard System
Fanuc
Speed Range
8000rpm
Transport Package
Seaworthy Packing
Specification
2700*2260*2400mm
Trademark
JT
Origin
China
HS Code
84581100
Production Capacity
1500
Product Description
Product Description
The 3 axis VMC-850 is a high performance CNC vertical machining center developed and manufactured by our company. The machine has the characteristics of high rigidity, high speed and high precision and has more advantages on operation and capabilities compared with similar products. All castings of the machine have been secondary tempered to provide excellent rigidity and stability for the whole machine. This machine applied with high rigid C design on structure, it also has been done with reinforcement on machine ribs.All the contact faces have been scraped manually, which guarantees the durability of accuracy. X/Y axes apply with two types of rolling guide way: ball bearing and roller guide way, which is optional that customer can choose base on customer's needs. Z axis applies roller guide way, which enables the machine to be with high rigidity, low noise, and small friction. The machine equips with an air tank, and the water can be drained out manually. Spindle is connected directly, and the highest speed can reach 8000RPM, which make this machie as a good choice for machining some complex parts with high efficiency.
Product Parameters
| Model | Specification | ||
| JT-VMC850 | Control System | Fanuc 0I TF PLUS | |
| Table size | mm | 1000×500 | |
| Maximum allowable load | kg | 500 | |
| T-slot dimensions | mm/piece | 5-18*90 | |
| Maximum table travel - X axis | mm | 800 | |
| Maximum table travel - Y axis | mm | 500 | |
| Maximum table travel - Z axis | mm | 500 | |
| Distance from spindle face to table surface | mm | 130-630 | |
| Distance from spindle center to Z-axis guide surface | mm | 540 | |
| Tapered hole(7:24) | BT 40 φ140 | ||
| Speed range | r/min | 8000 | |
| Spindle motor power | kw | 7.5/11 | |
| X/Y/Z axis rapid feed | m/min | 36/36/24 | |
| Linear guide width and type | X axis | 35mm roller | |
| Y axis | 35mm roller | ||
| Z axis | 35mm roller | ||
| Feed rate | mm/min | 1-10000 | |
| Tool changer type | Disk type | ||
| Tool magazine capacity | Handle | 24 | |
| Tool change time | s | 2.5 | |
| X/Y/Z axis repeatability | mm | ±0.005/300 | |
| Overall Dimensions | mm | 2700*2260*2400 | |
| Weight | kg | 5000 | |
