The Best Offer High Quality CNC Vertical Gear Hobbing Machine Max Dia. 500mm Max Module 8mm (MLT-YK3150HA)

Product Description

The same quality, lowest price; same price, best quality.

Project Description			Parameter Parameter
Processing Capacity. Processing capacity	Control the number of axes Axis		6 axes
	Type of machined workpiece Gear Type		Straight teeth, helical teeth, worm gear, splines Etc. Tooth parts
	Machining Accuracy		Grade 7 (GB/T10095-2008)
	Workpiece Workpiece	Max machined diameter Max.dia	500mm
		Max machining Module max.module	8mm
		Max machining Length Max.length	350mm
		Minimum number of machining teeth Min. Teeth Number	5 or more
	Cutter Tool	Maximum hob speed Max. Rotating speed	1000 r/min (customizable)
		Maximum length of hob Max. Tool Length	200mm
		Maximum outside diameter of hob Max.Hob Dia	180mm
		Diameter of the replaceable mandrel for the hob Dia of changeable center axis which assemble hobbing cutter	Phi 22, phi 27, phi 32,
		Tool change positioning accuracy Tool Position Accuracy	≤5um
		Y-direction channeling stroke Hob Shifting Travel	200mm
		Channeling method Hob shifting	Auto Auto
	Spindle Shaft	Spindle swing Angle Hob Head Swing Angle	±45° automatic swing Angle
	Turntable	Z-direction drag board Travel Z-Slide Travel	450mm
		Table diameter Turntable Dia	520mm
		Table RPM Turntable Max. RPM	180r/min
Machine Power power	Hob spindle Motor Power Main Motor Power		25kw
	Total machine Power Total Power		45kw
Size & Weight Size & Weight	Total Floor Space (L*W*H)		3300 * 3800 * 4000
	Machine Weight Machine weight		13000kg

Technical description
· CNC high-speed dual direct drive enhanced vertical model.
· Large processing diameter, large processing modulus, large processing height
· Equipped with MLT-G218v multi-axis dedicated high-end gear control system.
· The B and C axes are equipped with double direct drive servo motors as standard, which is more than fast, and the 5-mode processing is more than 3 times the efficiency of similar models.
· The whole machine has double-layer dynamic column structure, and the table is equipped with automatic hydraulic clamping system.
· Straight teeth, helical teeth, sprockets, timing wheels, rubber tooth belt molds, tooth-shaped
rollers, etc. can meet the roll cutting process.
· A modern gear machine with speed, precision, and flexible manufacturing in one essential feature.
· Quick installation function of hob, one key to release the knife, one key to lock the knife, to achieve quick replacement of hob.
MLT-YK3150HA vertical double direct drive CNC high speed gear hobbing machine is an excellent domestic vertical gear hobbing machine carefully developed by Mltor and with fully independent core technology. The machine is equipped with MLT gear hobbing special control system, original core gear processing algorithm software (non-secondary development macro program calculation), multi-axis NC servo drive technical advantages, BC axis adopts high-precision and high-torque servo direct drive motor (high-performance DD servo motor), with high speed, high-precision, high-torque and excellent dynamic response performance. It is equipped with workpiece hydraulic clamping cylinder and tailstock hydraulic lifting function. Compared with other similar equipment, it has the characteristics of high machining accuracy, high machining efficiency and good accuracy retention.
This machine tool is a 6-axis CNC high-speed gear hobbing machine working according to the expansion method, with three CNC linear axes: radial feed shaft (X-axis); Axial feed axis (Z axis); Tangential axis of motion (Y axis). Two CNC rotation axes: table rotation axis (C axis); Hob spindle rotation shaft (B axis); Automatic swing Angle (axis A)
