High Performance Small PP PE PVC Pet Recycled Plastic Bottle Crusher/Waste Plastic Crusher Machine for Baskets, Bottles

Product Description

High performance small PP PE PVC PET recycled plastic bottle crusher
Material of ACEEXTECH Crusher:
Basic data of ACEEXTECH Crusher:

GE Crusher
Model	GE500/500	GE500/700	GE500/1400
Rotor diamter	500mm	500mm	500mm
Rotor width	500mm	700mm	1400mm
Feeding opening	500*500mm	500*7000mm	500*1400mm
Drive motor	22KW	30KW	55KW
No. of rotor knives	6pcs, SKD-11	10pcs, SKD-11	10pcs, SKD-11
No. of stator knives	4pcs, SKD-11	4pcs, SKD-11	4pcs, SKD-11
Hydraulic drive	3.7KW	5.5KW	5.5KW
Screen size	10-14mm	10-14mm	10-14mm
Output capacity	300-500kg/h	500-700kg/h	800-1000kg/h
Cutting chamber and bearings are water proof version for wet processing of the granulator, Heavy duty type rack, hydraulic drive for hopper opening. Easy for blades maintain, Importing high quality blades from Europe.- Europe design, good performance for grinding, Rotor- in heavy duty version with 3-5row cutters tapped into rotor.

GH Crusher
Model	GH420/800	GH630/1000	GH700/1200	GH700/1400
Rotor diamter	420mm	630mm	700mm	700mm
Rotor width	800mm	1000mm	1200mm	1400mm
Feeding opening	420*800mm	630*7000mm	700*1200mm	700*1400mm
Drive motor	45KW	75KW	90KW	110KW
Motor brand	Siemens	Siemens	Siemens	Siemens
No. of rotor knives	6pcs, D2	10pcs, D2	14pcs, D2	14pcs, D2
No. of stator knives	4pcs, D2	4pcs, D2	4pcs, D2	4pcs, D2
Hydraulic drive	3.7KW	5.5KW	5.5KW	5.5KW
Screen size	10-14mm	10-14mm	10-14mm	10-14mm
Output capacity	400-600kg/h	800-1000kg/h	1000-1200kg/h	1200-1500kg/h
Cutting chamber and bearings are water proof version for wet processing of the granulator, Heavy duty type rack, hydraulic drive for hopper opening. Easy for blades maintain, Importing high quality blades from Europe.- Europe design, good performance for grinding, Rotor- in heavy duty version with 5-7row cutters tapped into rotor.

GF Crusher
Model	GF800	GF1000	GF1200
Rotor width	800mm	1000mm	1200mm
RPM	500	500	500
Drive motor	37KW	55KW	75KW
No. of rotor knives	6pcs, SKD-11	10pcs, SKD-11	10pcs, SKD-11
No. of stator knives	4pcs, SKD-11	4pcs, SKD-11	4pcs, SKD-11
Screen size	60mm	60mm	60mm
Output capacity	200-300kg/h	400-500kg/h	700-800kg/h
Cutting chamber and bearings are water proof version for wet processing of the crusher, Heavy duty type rack, hydraulic drive for hopper opening. Easy for blades maintain, Europe design, good performance for grinding, Special design for film and woven bag.

SC Series Crusher
Model	SC-20	SC-30	SC-50
Rotor diamter	350mm	380mm	500mm
Grinder Chamber	480*340mm	660*400mm	720*510mm
Drive motor	15KW	22KW	37KW
No. of rotor knives	3*8pcs, SKD-11	3*11pcs, SKD-11	3*12pcs, SKD-11
No. of stator knives	2*2pcs, SKD-11	2*2pcs, SKD-11	2*2pcs, SKD-11
Output capacity	120-180KG/H	240-300KG/H	400-500KG/H
Mesh	10-12mm	10-12mm	10-12mm

Specifications of ACEEXTECH Crusher:
Blade:Wear resistant alloy steel,Outboard design bearing, Work wet and dry
Rotor: With chevron "V" cutting angle
Bearing: NSK, Japan
Hydraulic:Quick access to cutting chamber, easy for blades maintain
Why choose us?
Safety
Safety cover
Strong welded construction
Humanity
Hydraulic control for maintenance
EFFICIENCY
Rotor with chevron "V" cutting angle
Outboard design bearing
Other advantages:
Lower investment cost for a high quality and durable machine;
Low energy consumption with high production output;
Fast machine delivery and installation:Aceextech produces on an average of 10 sets of plastic machine per month and can deliver the machine
faster than most manufacturers.
The regular delivery time of an Aceextech recycling machine is 90 working days.
