Indoor Outdoor Advertising Digital P2.97 P2.6 P3.91 P4.81 P2.97 LED Display Screen Cabinet Panel LED Sign Video Wall Billboard

Product Description

Product Description High precision P 2.6 P3.91,P2.976,P4.81 LED display screen with panel size 500x500mm,or 500x1000mm led display panels
Product Features: 1. SMD block lamp body ensure the high contrast ratio and high gray scale
2. Front and Rear access available modules,convenient and save much space for maintenance
3. High resolution for high definition,rich color display,perfect vision
4. Small pixel pitch for closed view distance,no stroble,friendly to eyes
5. Pure die-casting aluminum structure cabinet with size 500*500mm,easy for different screen size,light weight, easy to move and portable
6. Cabinets with angle adjuster for curved shapes to meet different request
Outdoor led display screen specification as following:

Model Number	P2.604	P2 .976	P3.91	P4.81
Model Size (mm)	250*250	250*250	250*250	250*250
Pixels Density(dots/m2)	147456	112896	65536	43264
Pixels Pitch (mm)	2.604	2.976	3.91	4.81
LED Package lamp	SMD1515	SMD1415LED	SMD1921	SMD1921/2525/2727
Pixel Resolution Dots(W)*(H)	96*96	84*84	64*64	52*52
Model Thickness(mm)	16	16	16	16
Model Weight(KG)	0.55	0.55	0.6	0.55
Brightness White Balance(CD/m2)	≥4500	≥4500	≥4500	≥4500
Cabinet Dimension(mm)	500*500	500*500	500*500/500*1000	500*500/500*1000
Power Supply	5V60A*PCS	5V60A* PCS	5V60A* PCS	5V60A* PCS
Screen resolution(dots)	192*192	168*168	128*128/128*256	101*104/104*208
Best Viewing Distance(m)	2.6-15	2 .976 - 15	3.9-15	4.81-15
Best Viewing Distance	140°(W)140°(H)	140 ° (W)140 ° (H)	140 ° (W)140 ° (H)	140 ° (W)140 ° (H)
Temperature	Storage:-35°c/+85°c	Storage: -35ºc/+85°c	Storage: -35ºC/+85ºC	Storage: -35ºC/+85ºC
Operation Humidity	10%-75%	10%-75%	10%-75%	10%-75%
Working Voltage	AC220V±10%	AC220V±10%	AC220V±10%	AC220V±10%
Max Power Consuption(W/m2)	≥560	≥400	≥200	≥400
Max Power Consuption(W/m2)	≥260	≥800	≥600	≥800
Control Method	Synchronization	Synchronization	Synchronization	Synchronization
Driving Device	Constant Drive	Constant Drive	Constant Drive	Constant Drive
Refresh Frequency	≥3840HZ	≥3840Hz	≥3840Hz	≥3840Hz
Frame Frequency	60Hz	60Hz	60Hz	60Hz
Luminance Level / Color	RGB256	RGB256	RGB256	RGB256
Gray Level	65536	65536	65536	65536

Indoor rental led screen specification:

Model No.	P2.6	P2.84	P2.9	P3.91	P4.81	P5.95	P6.25
Pixel Pitch	2.604mm	2.84mm	2.976mm	3.91mm	4.81mm	5.95mm	6.25mm
Led type	SMD1515	SMD1515	SMD2121	SMD2121	SMD2121	SMD3528	SMD3528
Resolution(dots/m2)	147456	123904	112896	65536	43264	288224	25600
Brightness(nits)	≤1200	≤1200	≥1200	≥1500	≥1500	≥1800	≥1800
Drive mode	1/22	1/22	1/28	1/16	1/13	1/17	1/10
Module size(mm)	250*250	250*250	250*250	250*250	250*250	250*250	250*250
Panel size(mm)	500*500	500*500	500*500	500*500	500*500	500*500	500*500
Panel resolution(dots/m2)	192*192	176*176	168*168	128*128	104*104	84*84	80*80
Cabinet weight(kgs)	8.6	8.6	8.6	8.0	8.0	8.0	8.0
Power consumption Max/Avg(W/M2)	800/350	800/350	800/350	600/300	600/300	700/300	560/280
View Angle(H°/V°)	160/140	160/140	160/140	160/140	160/140	160/140	160/140
Refresh rate(HZ)	>1920	>1920	>1920	>1920	>1920	>1920	>1920
Best view distance(m)	2~20	2.8~30	3~30	4~40	4.8~50	6~60	6~60
Protection level	IP31
Input power (V)	110V±10%
Working temperature	-20~+50ºC±10%
Working humidity	10%~90%
Control	Caste≤100m,Fiber optical≤10000m

Different cabinets for different requirement:
Packaging & Shipping Our packing of indoor outdoor rental led display screen packed in airflight case.
Company information:
We are the leading factory of LED display solutions, which has been specialized in R&D, manufacturing and marketing of LED Display Screens. Located in our own industrial park, JLLED covers a district of more than 8000 m², of three floors in one block. We could ensure production capacity of more than 5, 000 square meters per month for the LED displays, thanks to our well equipped automatic production lines, and skilled workers. Our R&D group is made of more than 8% of total employees and most of them are senior technicians, with more than 10 years' experiences in the LED field.
Our led screen export to Italy, USA, Thailand, Romania, Malaysia, Russia, etc for more than 6 years.
we have a strict quality control system and production processes,before delivery,we will check 3 days to ensure everything is ok
Our exhibition:
Certifications Our products have passed the test of international standards certifications, two years warranty ,after two years, only material cost to be charged.
FAQ Cooperation Terms:
1.Payment terms: 30% T/T deposit, 70% T/T before shipment. 2.Lead time:10-15 working days after payment of deposit.
Warranty: 3 years Within the warranty period, on the condition that all the goods are being used properly, if there is any problem with our goods, the customers can send the problem part back to us, we will fix the problem part, or replace the problem part with a new one.
Technical Support: We provide all kinds of technology training for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software,test reports, CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free.If required, we can send an engineer team to the country of the customer to instruct and help the installation.
Others: Free spare parts:A certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED diod,IC, module mask, power supply,receiving card,etc.
