Large vertical bed-type universal swivel head milling machine X716
| US$15,000.00-18,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
X716
Structure
Bed type
Milling Cutter Type
Vertical Milling Cutter
Milling Cutter Structure
Indexable Type
Controlling Mode
Artificial
Automatic Grade
Manual
Precision
High Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Table Size
2500X575mm
Long Travel
1800mm
Cross Travel
600mm
Vertical Travel
900mm
Taper
ISO50
Transport Package
Plywood Case
Specification
10000kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8459590000
Production Capacity
5PCS/Month
Product Description
BED TYPE VERTICAL UNIVERSAL MILLING MACHINE
bed type universal vertical swivel head milling machine
2.head swivel 360 degrees
3.with Control panel
4. Universal mill
SPECIFICATIONS:
| MODEL | X716 | ||
| Table size(L×W) | 2500mm×575mm | ||
| Min. distance from horizontal spindle axis to table surface | 30mm | ||
| Min. distance from vertical spindle nose to table surface | 49mm | ||
| Distance from vertical spindle axis to column guideway | 110mm | ||
| Table Travel | Longitudinal | 1800mm | |
| Cross | 600mm | ||
| Vertical | 900mm | ||
| Spindle speed | step | 16 | |
| Speed range | 40-1200 rpm/min | ||
| T slot No./width/Distance | 3/22/152 | ||
| Spindle taper | ISO50 | ||
| Feed speed range | Longitudinal | 20~2200 mm/min | |
| Cross | 20~2200 mm/min | ||
| Vertical feed speed range | 12~1320 mm/min | ||
| Rapid feed speed(X,Y) | 3000 mm/min | ||
| Rapid feed speed(Z) | 1800 mm/min | ||
| Motor power | 11KW(spindle motor)2.9KW(feed motor) | ||
| Max. Load of Table | 3000Kg | ||
| Overall size(mm) | 4300mm×3200mm×3300mm | ||
| Machine weight | 10000Kg | ||
| Contact Us: |
| Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
