UPVC PVC Seamless Welding Machine for Window and Door Profile UPVC Window Door Frame Profile Single Head Welding Machine

Product Description

Feature:
1.The machine is made up of 2 machine heads, machine frame, electric control tank and material supporting fame etc.
2.Can weld and clean the corner at one time. Specially for the colored profile.
3. There are fixing mechanism, pressing mechanism, heating mechanism and head box etc. on machine head.
4. The machine is used for PVC window and door welding processing; it can achieve the whole welding processing individually.
6. One of the machine heads can be used for welding processing with variable angles; it is also suitable for special shaped window welding like arch window.
Introduction
Vinyl/PVC/UPVC/Plastic window and door can clear welding beading at one time after finishing the welding, and can strictly control the size of welding seam; therefore, after welding of colorful section steel is finished, its surface welding creater looks perfect and top-grade, and its welding strength is higher than that of the original ones.
Through controlling pneumatic system, welding and cleaning(seamless) welding machine for Vinyl/PVC/plastic window increases processing mode of strengthening the welding strength,especially software processing in melting-welding clearance and welding process,thus it can guarantee optimal welding strength in various environments; it can also conduct quantitative adjustment according to digital parameters.
The cutter of the welding seamless machine adopts special material,via special heat-treatment processing technics and finish accuracy.The cutter is standardization completely, to achieve exchangeable,without professional the cutter can change without professional.
Technical Parameter

Model number	WFH3500.2A
Power supply	380V/220V 50Hz
Air consumption	180L/min
Input power	2.5kw
Welding length	420~3500mm
Welding profile height	10~100mm
Welding profile width	≤120mm
Welding mullion width	≤110mm
Operation air pressure	0.6 ~ 0.8Mpa
Humidity	≤80% (no dew)
Contour dimension(L×W×H)	4300×1050×1800mm
Temperature	0-300 degree
Machine weight(about)	500kg
Welding methods	Weld window frame Weld window-support Weld from free angle(we can do for you) Weld from 180 angle

Q: Are you manufacture?
A: Yes, we are the professional manufacture which have more than 5 workshops.
Q: How about the service?
A: 1).Reply it at once if from Ali-trade manager if by email,it reply it within 12 hour
2).Deliver max.days within 15 days
3).24 hours for after-sale service
4).More than 12 years experience in this kind machine field
5).Fluent English,communication barrier free
Q: What's the guarantee ?
A: 1).Our guarantee for 18 months.
2).24 hour's technical support by email or calling
3).English manual and video tutorial
4).2 year quality guaranty for the machine(excluding the consumables)
5).We will provide the consumable parts at an agency price
6).24 hours on line service each day,free technical support
Q: Do you provide equipment operation training?
A: Yes.We can send professional engineers to the working site for equipment installation,adjustment,and operation training. All of our engineers have passport.
Q: If our price is higher than another company or factories ?
A: Please check what is the different of the machine parts service and guarantee,especially the machine inner electric parts.Sometimes,if machines have breakdown, the most reason is the machine inner electric parts problem, but we use the famous and reiable parts for the machines inside.
Q: How long is the delivery time ?
A: For standard machines,it would be 3-15 days; For non-standard machines and customized machines according to clients specific requirements, it would be 15 to 30 days.
Q: What is the payment?
A: Any payment method you want, such as L/C,T/T,D/P,West-Union and so on.
