Factory Selling Professional Ca20 Power Amplifier High Power 2 Channel 1350W 8 Ohm Analog Audio Amplifier

Product Description

Factory Selling Professional CA20 Power Amplifier High Power 2 Channel 1350W 8 ohm Analog Audio Amplifier
Specification

Model		PA4	PA6	PA8	PA10	PA12	customized
Channel number		2	2	2	2	2	2
Rated output power	Stereo power 8Ω	400W	600W	800W	1000W	1200W	400W-1200W
	Stereo power 4Ω	600W	900W	1200W	1500W	1800W	600W-1800W
Rated bridged output power 8Ω		1200W	1800W	2400W	3000W	3600W	1200W-3600W
Power supply		AC 220-240V 50Hz/60Hz (100V-125V can be customized)
Total harmony distoration(THD)		<0.025%
Frequency response		20Hz-20KHz,±0.5dB
Signal to noise		>112dB
Slew rate		>100V/us
Damping factor		>1500:1
IMD		<0.05%
Input sensitivity(*40/32dB)		0.775V/1.4V(32dB)
Input impedance		20k ohms balance/10k ohms unbalance
Input CMRR		>80dB
Crosstalk		>80dB
Input link		One balance XLR interface per channel
Output link		One 4-POLESpeakon interface per channel and a pair of plum blossom anti-touch binding posts
Protection		Full-featured protection circuit, including temperature (overheating), short circuit, DC, voltage limit, overload, overcurrent, distortion limiter, undervoltage/overvoltage, on/off noise, load mismatch (low resistance), soft-start on boot, Power-on anti-surge, radio interference, secondary wave, high-frequency output automatic detection (UHF) protection and other protections
LED indicator		Protection (PEA), Signal (SIG), Overheating (TEM), Bridge (BRI), Stereo (STE), Mono (PAR)
Cooling system		By the air convection mechanism from the front to the rear, the internal air is forced to dissipate heat, and the automatic continuously variable speed dual fans are forced to cool
Output circuit type		Class H
Voltage gain 0.775V/0dB		*75	*92	*106	*120	*135	customized
Max power consumption		1000VA/4.3A	1500VA/6.5A	2000VA/8.7A	2500VA/10.9A	3500VA/15.2A	customized
Weight		13.5Kg	16.3Kg	16.8Kg	17.5Kg	25Kg	customized
Dimensions(L*D*H)		480*365*88mm			480*465*88mm
Remark:Above standard parameters are just for your reference,we can design by your requirements.

Model		PA4	PA6	PA8	PA10	Customized
Channel number		4	4	4	4	4
Rated output power	Stereo power 8Ω	400W	600W	800W	1000W	400W-1000W
	Stereo power 4Ω	600W	900W	1200W	1500W	600W-1500W
Rated bridged output power 8Ω		1200W	1800W	2400W	3000W	1200W-3000W
Power supply		AC 220-240V 50Hz/60Hz (100V-125V can be customized)
Total harmony distoration(THD)		<0.025%
Frequency response		20Hz-20KHz,±0.5dB
Signal to noise		>112dB
Slew rate		>100V/us
Damping factor		>1500:1
IMD		<0.05%
Input sensitivity(*40/32dB)		0.775V/1.4V(32dB)
Input impedance		20k ohms balance/10k ohms unbalance
Input CMRR		>80dB
Crosstalk		>80dB
Input link		One balance XLR interface per channel
Output link		One 4-POLESpeakon interface per channel and a pair of plum blossom anti-touch binding posts
Protection		Full-featured protection circuit, including temperature (overheating), short circuit, DC, voltage limit, overload, overcurrent, distortion limiter, undervoltage/overvoltage, on/off noise, load mismatch (low resistance), soft-start on boot, Power-on anti-surge, radio interference, secondary wave, high-frequency output automatic detection (UHF) protection and other protections
LED indicator		Protection (PEA), Signal (SIG), Overheating (TEM), Bridge (BRI), Stereo (STE), Mono (PAR)
Cooling system		By the air convection mechanism from the front to the rear, the internal air is forced to dissipate heat, and the automatic continuously variable speed dual fans are forced to cool
Output circuit type		Class H
Voltage gain 0.775V/0dB		*90	*100	*120	*130	Customized
Max power consumption		1700VA/7.6A	2300VA/10.2A	2700VA/12.6A	2960VA/14.3A	Customized
Weight		16Kg	18Kg	24Kg	26Kg	Customized
Dimensions(L*D*H)		480*465*88mm
Remark:Above standard parameters are just for your reference,we can design by your requirements.

Features
1. With high Slew Rate, strong ability to restore the details to get more clear and delicate high-frequency performance.2. With high Damping Factor, strong low-frequency control force to make a strong low-frequency straight extension.3. The high value of signal to noise ratio, to make sure get a better sound with high fidelity.4. The new circuit design, adopts the SMT surface mount technology, to improve the consistency and efficiency of the machine.5. Class AB circuit design, advanced power supply technology to reduce the overall power consumption by 40%, reducing the system heating and the weight of the product.6. Suitable for: KTV, stage performance,conference room, multi-function hall, bar ,theatrer and church etc.

Advantages of professional power amplifier
Audio amplifier appliance
Services
Package and Delivery
Welcome to contact us if interested.
