Evaporative Cooling Pad with Aluminum Alloy Frame Cooling Pad Wall for Poultry House Greenhouse Industrial Workshop Poultry Animal Husbandry Breeding
Basic Info.
Model NO.
7090 7060
Usage
Evaporative Air Water Cooling Ventilation
Application
Chicken Pig Cow
Power Source
Electric
Certification
ISO9001:2008, CE
Condition
New
Warranty
2 Years
Common Type
7090, Brown Color
Paper Material
Wood Pulp
Paper Weight
100g/Sqm
Height
1500/1800/2000mm
Width
600/300mm
Thickness of Pad
150/100mm
Paper Sheets
86 Sheets for Width 600mm
Cooling System
Water Cooling
Frame Available
Galvanized Sheet, Aluminum Alloy, Stainless Steel
Product Name
Karft Paper Evaporative Cooling Pad
Apply
Poultry House Greenhouse Industrial Workshop
Fuction
Evaporative Air Water Cooling Ventilation
Transport Package
Paper Carton
Specification
7090 7060 5090
Trademark
Yuyun Sanhe
Origin
China(Mainland)
HS Code
4823909000
Production Capacity
120cbm/Day
Product Description
Evaporative Cooling PadProduct Application YUYUN SANHE Evaporative cooling pad s mainly used for ventilation and air cooling in chicken farms, pig farms, greenhouses, factories, workshops, industrial etc.
Technical Parameter:
| Model | Height(mm) | Width(mm) | Thickness(mm) | Flute | Angle |
| 7090 | 1500/1800/2000/Customized | 300/600/Customized | 100/150/200/Customized | 7mm | 45°/45° |
| 7060 | 1500/1800/2000/Customized | 300/600/Customized | 100/150/200/Customized | 7mm | 45°/45° |
| 5090 | Customized | Customized | Customized | 5mm | 45°/45° |
Product Description:
| 1. YUYUN SANHE cooling pad use new material and space crossing linking technology, high water absorbability ,high water-resistance, anti-mildew and long service life 2. The Product contains surface active agent for natural water absorbability ,fast pervasion speed, lasting effectiveness. 3. Strict production as per standard, width of 600mm cooling pad involves 85 sheets 4. Raw material adopts imported kraft paper, we have 95g/sqm and 105g/sqm for option. Tension resistance at 70N, Absorbability height as 45mm/10min, moisture at 5-8%, humidity at 18N 5. Products don't contain Phenol or any other chemical substances which easily makes skin allergy. Non-toxic and harmless to human body, safety, energy saving, environment protection and economic applicable. | ||
| 1. According to customers' requirement ,we can do one side color coated cooling pad for easy cleaning and beautiful appearance. 2. Color is for option: black coated/ green coated/ yellow coated/ red coated/blue coated/ orange coated and so on. | ||
| Three Material of Frame for Customer Choice | ||
About our Company
Shandong Yuyun Sanhe Machinery Co.,Ltd is the biggest and the most professional manufacturer of ventilation equipment in
China,equipped with the most advanced CNC production lines and laser cutting machines, top quality level in the industry.
