550W 50-2500 Rpm Variable Speed 7X14 Inch Bench Top Mini Metal Lathe

Product Description

Products Description
Brief introduction
The 7 x 14 Inch Precision Mini Benchtop Lathe features a 3-jaw chuck, a MT3 spindle taper, a MT2 tailstock taper, a tool rest and a 3/4 HP motor, designed to perform various types of metal turning, simple to operate. Through high frequency quenching process and precision grinding of high-quality cast iron bed. 0-2250Rpm spindle speed sub-level of two tranches spindle gear change speed control, continuously adjustable.




Heavy & Sturdy Machine
This lathe features an MT#2 taper and all the adjustment capability you need to work securely and accurately. It has a swing over bed of 7.09" / 180 mm and a swing over cross slide of 14" / 350 mm, so you can handle large projects.







Infinitely Variable Speeds
Variable speed from 0-2250 RPM. The feed speed can be adjusted according to the requirements of different workpieces. This metal lathe includes a large through-hole shaft to avoid inconvenience while working long pieces.
Four-way Tool Post
T-slotted compound slide with four-way tool post, 4 blades avaliable at most, easy to change quickly. Bevel cutting can be made by adjusting the angle of the compound rest with the lever.
High Accuracy Chuck
3-jaw self-centering chuck has gone tested with accuracy and repeatability to set cylindrical materials steadily. Backsplash guard included. Spindle is supported by precision tapered roller bearings, spindle accuracy within 0.01mm.
Specifcation

Power of Motor	550W DC Single Phase
Swing Over Cross Slide	4.3" / 110 mm
Centers Distance	13.78" / 350 mm
Spindle Taper	MT3
Cross Slide Travel	2.53" / 65 mm
Metric Thread	0.5 - 2.5 mm
Spindle Speed	0 - 2250 RPM
Chuck Diameter	3.94" / 100 mm
Spindle Bore	0.83" / 21 mm
Tailstock Taper	MT2
Top Slide Travel	1.36" / 35 mm
Net Weight	102.7 lbs / 46.6 kg
Item Dimensions (L x W x H)	29.4 x 8.7 x 10.8 in / 74.7 x 22 x 27.4 cm

Company Profile
SJR Machinery Co., Ltd. , was founded in 1984, which is the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. Our company specializes in the manufacture and import/export of brand new industrial machinery and tools. We are capable of producing more than 80 types of machines.Sincerely welcoming you to contact us for more information, we look forward to becoming your supplier in the near future.
Order Evaluation
Exhibition
Customer Photos
Certifications
FAQ
1. How can I choose the most suitable machines ? A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .

2. What is your payment terms ?
A: 30% down-payment after contract ,and 70% payment before shipment, Meanwhite it can be discussed according to your situation.

3: Where is our factory located? How can I visit there?
A : Our factory is located in No. 52 Linyin Road, Economic and Technological Development Zone, Nantong City, Jiangsu Province ,226001 China. You are warmly welcomed to visit us.

4. What is your delivery time ?
The delivery depends on different machines with different configurations. Please contact us to confirm it is in stock or not.

5. Can you send the service engineer to our company ?
We have engineers stationed in Canada, Egypt, and Algeria. The after-sales service system is very perfect.
