Basic Info.
Special Function
Soundproof
Certification
CCC, ISO9001, RoHS, CE
Surface Finishing
Finished
Single Door Leaf Widths
700mm to 1500mm
Bi-Parting Door Leaf Widths
650mm to 1350mm
Single Door Leaf Weights
120kg
Bi-Parting Door Leaf Weights
120kgx2
Single Slide or Bi-Psrting Action
up to 3000mm Clear Opening Widths
Sound-Damping with Replaceable Track Rai
Back-up Battery Use on Emergency
Transport Package
Stardand Carton Package
Specification
CE, RoHS, SGS, UL
Origin
Shenzhen, Guangdong, China
Production Capacity
1000sets/Month
Product Description
Original Dunker motor Automatic Sliding Door Drive
S20 automatic sliding door drive system : 1. Excellent quality.Use original real Dunker motor
2. Long service life.Tested for more than 5 years.
3. Safety.No any sensitive safety equipment although, When meet a balloon, door panels will reverse softly.
4. Silent.The track rail is coved by a pad which can reduce noise and protect wheels.
6. Meet European safety standard EN16005 and DIN18650.
7. 80-250v power supply.
Standard Configuration
1. Minidrive Unit
2. Transformer
3. Motor
4. Decoder
5. Basic control module
6. Track
7. Carrier
8. Return Pully
9. Service cover holder
10. End stop
11. Door bracket
12. Belt connection
13. Belt tensioning device
Opetional Parts
Motion Sensor
Lock latch
Battery
Beam safety photocell
Additional
Low noise desigh (<40db)
One million times of tests passed
Warranty: 36 months Emergency Functions
Emergency opening in case of power failure / Fail-safe
Obstacle detection with automatic return mechanism
Self monitoring light barriers
Slow speed search for obstruction
Technical Specification
Model | S20 |
Door range | Single leaf | Double leaf |
Door leaf weight | Max 200kg*1 | Max 160kg*2 |
Door width | 800~3000mm | 700~1500mm |
Opening speed | 100~750mm/s(Adjustable) |
Closing speed | 100~750mm/s(Adjustable) |
Opening time | 0~9 seconds |
Motor | Dunker Motor |
Supply voltage | Input AC 110V/220V;50-60Hz |
Working temperature | -20~50°C |
Working noise | Less than 45 db
|
Dunker Motor :
Controller:
Carriage wheel :
ES200 Automatic sliding door drive:
