LED Driver 100W Constant Voltage 12V LED Switching Power Supply

Product Description

Led driver 100w constant voltage 12v led switching power supply
Features:

-12V20W Waterproof LED power supply, constant voltage.
-Epoxy encapsulated, IP67. Suitable for outdoor lighting application.
-Automated protection for over load and over temperature
-Aluminum housing, good for heat dissipation
-Cooling by free air convection.
-Application: LED display, LED sign, LED channel letter, LED underwater light, LED outdoor decorative lighting.
Specification:

AC Input	Voltage	90-264V AC	90-264V AC
	Frequency	47-63 Hz	47-63 Hz
	AC Current	0.82A max@220V	0.80A max@220V
	Efficiency	81%	85%
DC Output	Voltage	12±0.5V	24±0.5V
	Current	0-5A	0-2.5A
	Rated Power	60W	60W
Protection	Over Load	20% exceed in short time is allowed
	Short Circuit	Auto recovery
	Over Voltaqge	≤280V
	Over Temperature	≤85°C
Others	Store Temperature	- 40--85°C
	Wokring Temperature	- 20--55°C
	Dimension/Weight	138x70x40mm / 800g (Aluminium Housing)
	Packing/Carton Size	20PC/CTN 45*20.3*26 cm
	Input Cable	VDE H03VV-F 3G×0.75mm2 (200mm)
	Output Cable	VDE H03VV-F 2×0.75mm2 (200mm)
Certificate	CE	Compliant to EN 60950-1:2006;EN61000-6-3:2001; EN 55022:2006+A1:2007; EN61000-4-2/-3; EN61000-6-1:2001; EN55024:1998+A1:2000+A2:2003
	RoHs	Free from lead, Cadmium, Mercury, Hexavalent Chromium and/or PBB &PBDE
